Nexperia的低功耗、快速双极性系列高压晶体管非常适合任何功率应用中的高频切换。需要可以承受高压脉冲(EMI要求)的双极性晶体管?敬请查看Nexperia的击穿电压高达400 V的高压器件。Nexperia的高压晶体管适合用于LCD背光、HID前灯照明以及CFL照明应用中的半桥开关。

  • 高VCEO
  • 低VCEsat

典型应用

  • 有线电信用挂钩开关
  • 高电流LED驱动器、LCD背光
  • CFL照明中的半桥开关
  • 开关模式电源(低功耗)
  • HID前置照明
选型表下载
Type numberPackage versionPackage nameSize (mm)hFE minProduct statusfT min (MHz)PolarityIC max (mA)VCEO max (V)Ptot max (mW)ComplementhFE max
BF620SOT89SOT894.5 x 2.5 x 1.550Production60NPN503001250BF621>50
BF622SOT89SOT894.5 x 2.5 x 1.550Production60NPN502501250BF623>50
BF621SOT89SOT894.5 x 2.5 x 1.550Production60PNP503001250BF620>50
BF623SOT89SOT894.5 x 2.5 x 1.550Production60PNP502501250BF622>50
BF720SOT223SC-736.5 x 3.5 x 1.6550Production60NPN503001200 >50
BF722SOT223SC-736.5 x 3.5 x 1.6550Production60NPN502501200BF723>50
BF723SOT223SC-736.5 x 3.5 x 1.6550Production60PNP502501200BF722>50
BF820SOT23SOT232.9 x 1.3 x 150Production60NPN50300250BF821>50
BF822SOT23SOT232.9 x 1.3 x 150Production60NPN50250250BF823>50
BF820WSOT323SC-702 x 1.25 x 0.9550Production60NPN50300200 >50
BF821SOT23SOT232.9 x 1.3 x 150Production60PNP50300250BF820>50
BF823SOT23SOT232.9 x 1.3 x 150Production60PNP50250250BF822>50
BSP19SOT223SC-736.5 x 3.5 x 1.6540Production70NPN503501200 >40
BSR19ASOT23SOT232.9 x 1.3 x 180Production100NPN300160250BSR20A>80
BSS63SOT23SOT232.9 x 1.3 x 130Production85PNP100100250BSS64>30
BST39SOT89SOT894.5 x 2.5 x 1.540Production70NPN1003501300BST15>40
MMBTA42SOT23SOT232.9 x 1.3 x 140Production50NPN100300250MMBTA92>40
MMBTA92SOT23SOT232.9 x 1.3 x 140Production50PNP100300250MMBTA42>40
PMBT5550SOT23SOT232.9 x 1.3 x 160Production100NPN300140250PMBT5401250
PMBT5551SOT23SOT232.9 x 1.3 x 180Production100NPN300160250PMBT5401250
PMBTA42SOT23SOT232.9 x 1.3 x 140Production50NPN100300250PMBTA92>40
PMBTA42DSSOT457SC-74; TSOP62.9 x 1.5 x 1 Production
PMBTA92SOT23SOT232.9 x 1.3 x 140Production50PNP100300250PMBTA42>40
PMST5550SOT323SC-702 x 1.25 x 0.9560Production100NPN300140200PMST5401250
PMST5551SOT323SC-702 x 1.25 x 0.9580Production100NPN300160200PMST5401250
PMSTA42SOT323SC-702 x 1.25 x 0.9540Production50NPN500300200PMSTA92>40
PMSTA92SOT323SC-702 x 1.25 x 0.9540Production50PNP500300200PMSTA42>40
PXTA42SOT89SOT894.5 x 2.5 x 1.540Production50NPN1003001300PXTA92>40
PXTA92SOT89SOT894.5 x 2.5 x 1.540Production50PNP1003001300PXTA42>40
PZTA42SOT223SC-736.5 x 3.5 x 1.6540Production50NPN1003001200 >40
PZTA44SOT223SC-736.5 x 3.5 x 1.6540Production20NPN3004001350 >40
PZTA92SOT223SC-736.5 x 3.5 x 1.6540Production50PNP1003001200PZTA42>40
数据手册
  • 点击选型表型号,下载数据手册
