选型表下载

Type number	Product status	Family	Type	Description	VCC (V)	Logic switching levels	Output drive capability (mA)	tpd (ns)	fmax (MHz)	No of bits	Power dissipation considerations	Tamb (°C)	Rth(j-a) (K/W)	Ψth(j-top) (K/W)	Rth(j-c) (K/W)	No of pins	Package name	Package version	Function
74ABT00D	Production	ABT	NAND gates	Quad 2-input NANDgate	4.5 - 5.5	TTL	-15 / +20	2.5	100	4	medium	-40~85	106	18.9	64	14	SO14	SOT108-1	NAND gates
74ABT00PW	Production	ABT	NAND gates	Quad 2-input NANDgate	4.5 - 5.5	TTL	-15 / +20	2.5	100	4	medium	-40~85	140	7.4	66	14	TSSOP14	SOT402-1	NAND gates
74ABT08D	Production	ABT	AND gates	Quad 2-input AND gate	4.5 - 5.5	TTL	-15/+20	2.4	100	4	medium	-40~85	106	18.9	64	14	SO14	SOT108-1	AND gates
74ABT08PW	Production	ABT	AND gates	Quad 2-input AND gate	4.5 - 5.5	TTL	-15/+20	2.4	100	4	medium	-40~85	140	7.4	66	14	TSSOP14	SOT402-1	AND gates
74ABT20D	Production	ABT	NAND gates	Dual 4-input NANDgate	4.5 - 5.5	TTL	-15 / +20	2.7	100	2	medium	-40~85	106	18.9	64	14	SO14	SOT108-1	NAND gates
74ABT20PW	Production	ABT	NAND gates	Dual 4-input NANDgate	4.5 - 5.5	TTL	-15 / +20	2.7	100	2	medium	-40~85	140	7.4	66	14	TSSOP14	SOT402-1	NAND gates
74ABT32D	Production	ABT	OR gates	Quad 2-input OR gate	4.5 - 5.5	TTL	-15 / +20	2.3	100	4	medium	-40~85	106	18.9	64	14	SO14	SOT108-1	OR gates
74ABT32PW	Production	ABT	OR gates	Quad 2-input OR gate	4.5 - 5.5	TTL	-15 / +20	2.3	100	4	medium	-40~85	140	7.4	66	14	TSSOP14	SOT402-1	OR gates
74AHC1G09GV	Production	AHC(T)	AND gate	Single 2-input ANDgate; open-drain	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	AND gates
74AHC1G09GW	Production	AHC(T)	AND gate	Single 2-input ANDgate; open-drain	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	AND gates
74AHC1G00GV	Production	AHC(T)	NAND gate	Single 2-input NANDgate	2.0 - 5.5	CMOS	± 8	3.5	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	NAND gates
74AHC1G00GW	Production	AHC(T)	NAND gate	Single 2-input NANDgate	2.0 - 5.5	CMOS	± 8	3.5	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	NAND gates
74AHCT1G00GV	Production	AHC(T)	NAND gate	Single 2-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.6	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	NAND gates
74AHCT1G00GW	Production	AHC(T)	NAND gate	Single 2-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.6	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	NAND gates
74AHC1G02GV	Production	AHC(T)	NOR gate	Single 2-input NORgate	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	NOR gates
74AHC1G02GW	Production	AHC(T)	NOR gate	Single 2-input NORgate	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	NOR gates
74AHCT1G02GV	Production	AHC(T)	NOR gate	Single 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.5	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	NOR gates
74AHCT1G02GW	Production	AHC(T)	NOR gate	Single 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.5	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	NOR gates
74AHC1G08GV	Production	AHC(T)	AND gate	Single 2-input ANDgate	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	AND gates
74AHC1G08GW	Production	AHC(T)	AND gate	Single 2-input ANDgate	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	AND gates
74AHCT1G08GV	Production	AHC(T)	AND gate	Single 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.6	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	AND gates
74AHCT1G08GW	Production	AHC(T)	AND gate	Single 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.6	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	AND gates
74AHC1G32GV	Production	AHC(T)	OR gate	Single 2-input ORgate	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	OR gates
74AHC1G32GW	Production	AHC(T)	OR gate	Single 2-input ORgate	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	OR gates
74AHCT1G32GV	Production	AHC(T)	OR gate	Single 2-input ORgate	4.5 - 5.5	TTL	± 8	3.3	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	OR gates
74AHCT1G32GW	Production	AHC(T)	OR gate	Single 2-input ORgate	4.5 - 5.5	TTL	± 8	3.3	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	OR gates
74AHC1G86GV	Production	AHC(T)	EXCLUSIVE-OR gate	2-input EXCLUSIVE-ORgate	2.0 - 5.5	CMOS	± 8	3.4	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	EXCLUSIVE-OR gates
74AHC1G86GW	Production	AHC(T)	EXCLUSIVE-OR gate	2-input EXCLUSIVE-ORgate	2.0 - 5.5	CMOS	± 8	3.4	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	EXCLUSIVE-OR gates
74AHCT1G86GV	Production	AHC(T)	EXCLUSIVE-OR gate	2-input EXCLUSIVE-ORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.5	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	EXCLUSIVE-OR gates
74AHCT1G86GW	Production	AHC(T)	EXCLUSIVE-OR gate	2-input EXCLUSIVE-ORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.5	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	EXCLUSIVE-OR gates
74AHC2G00DC	Production	AHC(T)	NAND gates	Dual 2-input NANDgate	2.0 - 5.5	CMOS	± 8	3.5	60	2	low	-40~125	205	35.8	116	8	VSSOP8	SOT765-1	NAND gates
74AHC2G00DP	Production	AHC(T)	NAND gates	Dual 2-input NANDgate	2.0 - 5.5	CMOS	± 8	3.5	60	2	low	-40~125	218	20.9	106	8	TSSOP8	SOT505-2	NAND gates
74AHCT2G00DC	Production	AHC(T)	NAND gates	Dual 2-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.6	60	2	low	-40~125	205	35.8	116	8	VSSOP8	SOT765-1	NAND gates
74AHC2G08DC	Production	AHC(T)	AND gates	Dual 2-input AND gate	2.0 - 5.5	CMOS	± 8	3.2	60	2	low	-40~125	205	35.8	116	8	VSSOP8	SOT765-1	AND gates
74AHC2G08DP	Production	AHC(T)	AND gates	Dual 2-input AND gate	2.0 - 5.5	CMOS	± 8	3.2	60	2	low	-40~125	218	20.9	106	8	TSSOP8	SOT505-2	AND gates
74AHCT2G08DC	Production	AHC(T)	AND gates	Dual 2-Input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.6	60	2	low	-40~125	205	35.8	116	8	VSSOP8	SOT765-1	AND gates
74AHCT2G08DP	Production	AHC(T)	AND gates	Dual 2-Input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.6	60	2	low	-40~125	218	20.9	106	8	TSSOP8	SOT505-2	AND gates
74AHC2G32DC	Production	AHC(T)	OR gates	Dual 2-input OR gate	2.0 - 5.5	CMOS	± 8	3.2	60	2	low	-40~125	205	35.8	116	8	VSSOP8	SOT765-1	OR gates
74AHC2G32DP	Production	AHC(T)	OR gates	Dual 2-input OR gate	2.0 - 5.5	CMOS	± 8	3.2	60	2	low	-40~125	218	20.9	106	8	TSSOP8	SOT505-2	OR gates
74AHCT2G32DC	Production	AHC(T)	OR gates	Dual 2-input OR gate	4.5 - 5.5	TTL	± 8	3.3	60	2	low	-40~125	205	35.8	116	8	VSSOP8	SOT765-1	OR gates
74AHCT2G32DP	Production	AHC(T)	OR gates	Dual 2-input OR gate	4.5 - 5.5	TTL	± 8	3.3	60	2	low	-40~125	218	20.9	106	8	TSSOP8	SOT505-2	OR gates
74AHC00BQ	Production	AHC(T)	NAND gates	Quad 2-input NANDgate	2.0 - 5.5	CMOS	± 8	3.2	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	NAND gates
74AHC00D	Production	AHC(T)	NAND gates	Quad 2-input NANDgate	2.0 - 5.5	CMOS	± 8	3.2	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	NAND gates
74AHC00PW	Production	AHC(T)	NAND gates	Quad 2-input NANDgate	2.0 - 5.5	CMOS	± 8	3.2	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	NAND gates
74AHCT00BQ	Production	AHC(T)	NAND gates	Quad 2-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.3	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	NAND gates
74AHCT00D	Production	AHC(T)	NAND gates	Quad 2-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.3	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	NAND gates
74AHCT00PW	Production	AHC(T)	NAND gates	Quad 2-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.3	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	NAND gates
74AHC02BQ	Production	AHC(T)	NOR gates	Quad 2-input NOR gate	2.0 - 5.5	CMOS	± 8	2.9	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	NOR gates
74AHC02D	Production	AHC(T)	NOR gates	Quad 2-input NOR gate	2.0 - 5.5	CMOS	± 8	2.9	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	NOR gates
74AHC02PW	Production	AHC(T)	NOR gates	Quad 2-input NOR gate	2.0 - 5.5	CMOS	± 8	2.9	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	NOR gates
74AHCT02BQ	Production	AHC(T)	NOR gates	Quad 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.8	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	NOR gates
74AHCT02D	Production	AHC(T)	NOR gates	Quad 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.8	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	NOR gates
74AHCT02PW	Production	AHC(T)	NOR gates	Quad 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.8	60	4	low	-40~125	138	1	8	14	TSSOP14	SOT402-1	NOR gates
74AHC08BQ	Production	AHC(T)	AND gates	Quad 2-input AND gate	2.0 - 5.5	CMOS	± 8	3.5	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	AND gates
74AHC08D	Production	AHC(T)	AND gates	Quad 2-input AND gate	2.0 - 5.5	CMOS	± 8	3.5	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	AND gates
74AHC08PW	Production	AHC(T)	AND gates	Quad 2-input AND gate	2.0 - 5.5	CMOS	± 8	3.5	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	AND gates
74AHCT08BQ	Production	AHC(T)	AND gates	Quad 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	5	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	AND gates
74AHCT08D	Production	AHC(T)	AND gates	Quad 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	5	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	AND gates
74AHCT08PW	Production	AHC(T)	AND gates	Quad 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	5	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	AND gates
74AHC30BQ	Production	AHC(T)	NAND gates	8-input NAND gate	2.0 - 5.5	CMOS	± 8	3.6	60	1	low	-40~125	108	22.7	76	14	DHVQFN14	SOT762-1	NAND gates
74AHC30D	Production	AHC(T)	NAND gates	8-input NAND gate	2.0 - 5.5	CMOS	± 8	3.6	60	1	low	-40~125	111	21.9	69	14	SO14	SOT108-1	NAND gates
74AHC30GU12	Production	AHC(T)	NAND gates	8-input NAND gate	2.0 - 5.5	CMOS	± 8	3.6	60	1	low	-40~125				12	XQFN12	SOT1174-1	NAND gates
74AHC30PW	Production	AHC(T)	NAND gates	8-input NAND gate	2.0 - 5.5	CMOS	± 8	3.6	60	1	low	-40~125	143	8.5	69	14	TSSOP14	SOT402-1	NAND gates
74AHCT30BQ	Production	AHC(T)	NAND gates	8-input NAND gate;TTL enabled	4.5 - 5.5	TTL	± 8	3.3	60	1	low	-40~125	108	22.7	76	14	DHVQFN14	SOT762-1	NAND gates
74AHCT30D	Production	AHC(T)	NAND gates	8-input NAND gate;TTL enabled	4.5 - 5.5	TTL	± 8	3.3	60	1	low	-40~125	111	21.9	69	14	SO14	SOT108-1	NAND gates
74AHCT30PW	Production	AHC(T)	NAND gates	8-input NAND gate;TTL enabled	4.5 - 5.5	TTL	± 8	3.3	60	1	low	-40~125	143	8.5	69	14	TSSOP14	SOT402-1	NAND gates
74AHC32BQ	Production	AHC(T)	OR gates	Quad 2-input OR gate	2.0 - 5.5	CMOS	± 8	3.5	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	OR gates
74AHC32D	Production	AHC(T)	OR gates	Quad 2-input OR gate	2.0 - 5.5	CMOS	± 8	3.5	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	OR gates
74AHC32PW	Production	AHC(T)	OR gates	Quad 2-input OR gate	2.0 - 5.5	CMOS	± 8	3.5	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	OR gates
74AHCT32BQ	Production	AHC(T)	OR gates	Quad 2-input OR gate;TTL enabled	4.5 - 5.5	TTL	± 8	5	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	OR gates
74AHCT32D	Production	AHC(T)	OR gates	Quad 2-input OR gate;TTL enabled	4.5 - 5.5	TTL	± 8	5	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	OR gates
74AHCT32PW	Production	AHC(T)	OR gates	Quad 2-input OR gate;TTL enabled	4.5 - 5.5	TTL	± 8	5	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	OR gates
74AHC86BQ	Production	AHC(T)	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate	2.0 - 5.5	CMOS	± 8	3.4	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	EXCLUSIVE-OR gates
74AHC86D	Production	AHC(T)	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate	2.0 - 5.5	CMOS	± 8	3.4	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	EXCLUSIVE-OR gates
74AHC86PW	Production	AHC(T)	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate	2.0 - 5.5	CMOS	± 8	3.4	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	EXCLUSIVE-OR gates
74AHCT86BQ	Production	AHC(T)	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate; TTL enabled	4.5 - 5.5	TTL	± 8	3.4	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	EXCLUSIVE-OR gates
74AHCT86D	Production	AHC(T)	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate; TTL enabled	4.5 - 5.5	TTL	± 8	3.4	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	EXCLUSIVE-OR gates
74AHCT86PW	Production	AHC(T)	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate; TTL enabled	4.5 - 5.5	TTL	± 8	3.4	60	4	low	-40~125	138	1	64	14	TSSOP14	SOT402-1	EXCLUSIVE-OR gates
74AHC132BQ	Production	AHC(T)	NAND gates	Quad 2-input NANDgate Schmitt-trigger	2.0 - 5.5	CMOS	± 8	3.3	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	Schmitt-triggers
74AHC132D	Production	AHC(T)	NAND gates	Quad 2-input NANDgate Schmitt-trigger	2.0 - 5.5	CMOS	± 8	3.3	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	Schmitt-triggers
74AHC132PW	Production	AHC(T)	NAND gates	Quad 2-input NANDgate Schmitt-trigger	2.0 - 5.5	CMOS	± 8	3.3	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	Schmitt-triggers
74AHCT132BQ	Production	AHC(T)	NAND gates	Quad 2-input NANDgate Schmitt-trigger; TTL enabled	4.5 - 5.5	TTL	± 8	3.5	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	Schmitt-triggers
74AHCT132D	Production	AHC(T)	NAND gates	Quad 2-input NANDgate Schmitt-trigger; TTL enabled	4.5 - 5.5	TTL	± 8	3.5	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	Schmitt-triggers
74AHCT132PW	Production	AHC(T)	NAND gates	Quad 2-input NANDgate Schmitt-trigger; TTL enabled	4.5 - 5.5	TTL	± 8	3.5	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	Schmitt-triggers
74ALVC00BQ	Production	ALVC	NAND gates	Quad 2-input NANDgate	1.65 - 3.6	TTL	± 24	2.1	145	4	low	-40~85	103	18.3	71	14	DHVQFN14	SOT762-1	NAND gates
74ALVC00D	Production	ALVC	NAND gates	Quad 2-input NANDgate	1.65 - 3.6	TTL	± 24	2.1	145	4	low	-40~85	103	17.1	62	14	SO14	SOT108-1	NAND gates
74ALVC00PW	Production	ALVC	NAND gates	Quad 2-input NANDgate	1.65 - 3.6	TTL	± 24	2.1	145	4	low	-40~85	138	6.9	64	14	TSSOP14	SOT402-1	NAND gates
74ALVC02BQ	Production	ALVC	NOR gates	Quad 2-input NOR gate	1.65 - 3.6	TTL	± 24	2.2	150	4	low	-40~85	103	18.3	71	14	DHVQFN14	SOT762-1	NOR gates
74ALVC02D	Production	ALVC	NOR gates	Quad 2-input NOR gate	1.65 - 3.6	TTL	± 24	2.2	150	4	low	-40~85	103	17.1	62	14	SO14	SOT108-1	NOR gates
74ALVC02PW	Production	ALVC	NOR gates	Quad 2-input NOR gate	1.65 - 3.6	TTL	± 24	2.2	150	4	low	-40~85	138	1	64	14	TSSOP14	SOT402-1	NOR gates
74ALVC08BQ	Production	ALVC	AND gates	Quad 2-input AND gate	1.65 - 3.6	TTL	± 24	2	150	4	low	-40~85	103	18.3	71	14	DHVQFN14	SOT762-1	AND gates
74ALVC08D	Production	ALVC	AND gates	Quad 2-input AND gate	1.65 - 3.6	TTL	± 24	2	150	4	low	-40~85	103	17.1	62	14	SO14	SOT108-1	AND gates
74ALVC08PW	Production	ALVC	AND gates	Quad 2-input AND gate	1.65 - 3.6	TTL	± 24	2	150	4	low	-40~85	138	6.9	64	14	TSSOP14	SOT402-1	AND gates
74ALVC32BQ	Production	ALVC	OR gates	Quad 2-input OR gate	1.65 - 3.6	TTL	± 24	2	150	4	low	-40~85	103	18.3	71	14	DHVQFN14	SOT762-1	OR gates
74ALVC32D	Production	ALVC	OR gates	Quad 2-input OR gate	1.65 - 3.6	TTL	± 24	2	150	4	low	-40~85	103	17.1	62	14	SO14	SOT108-1	OR gates
74ALVC32PW	Production	ALVC	OR gates	Quad 2-input OR gate	1.65 - 3.6	TTL	± 24	2	150	4	low	-40~85	138	6.9	64	14	TSSOP14	SOT402-1	OR gates
74AUP1G00GM	Production	AUP	NAND gate	Single 2-input NANDgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	1	ultra low	-40~125	311	7.7	157	6	XSON6	SOT886	NAND gates
74AUP1G00GN	Production	AUP	NAND gate	Single 2-input NANDgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	1	ultra low	-40~125	334	22.6	207	6	XSON6	SOT1115	NAND gates
74AUP1G00GS	Production	AUP	NAND gate	Single 2-input NANDgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	1	ultra low	-40~125	321	28.7	215	6	XSON6	SOT1202	NAND gates
74AUP1G00GW	Production	AUP	NAND gate	Single 2-input NANDgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	1	ultra low	-40~125	309	79.2	179	5	TSSOP5	SOT353-1	NAND gates
74AUP1G00GX	Production	AUP	NAND gate	Single 2-input NANDgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	1	ultra low	-40~125	322	90.7	191	5	X2SON5	SOT1226	NAND gates
74AUP1G02GM	Production	AUP	NOR gate	Single 2-input NORgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	1	ultra low	-40~125	311	7.7	157	6	XSON6	SOT886	NOR gates
74AUP1G02GN	Production	AUP	NOR gate	Single 2-inputNOR gate	1.1 - 3.6	CMOS	± 1.9	8.3	70	1	ultra low	-40~125	334	22.6	207	6	XSON6	SOT1115	NOR gates
74AUP1G02GS	Production	AUP	NOR gate	Single 2-input NORgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	1	ultra low	-40~125	321	28.7	215	6	XSON6	SOT1202	NOR gates
74AUP1G02GW	Production	AUP	NOR gate	Single 2-input NORgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	1	ultra low	-40~125	309	79.2	179	5	TSSOP5	SOT353-1	NOR gates
74AUP1G02GX	Production	AUP	NOR gate	Single 2-input NORgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	1	ultra low	-40~125	322	90.7	191	5	X2SON5	SOT1226	NOR gates
74AUP1G08GM	Production	AUP	AND gate	Single 2-input ANDgate	1.1 - 3.6	CMOS	± 1.9	8.2	70	1	ultra low	-40~125	311	7.7	157	6	XSON6	SOT886	AND gates
74AUP1G08GN	Production	AUP	AND gate	Single 2-input ANDgate	1.1 - 3.6	CMOS	± 1.9	8.2	70	1	ultra low	-40~125	334	22.6	207	6	XSON6	SOT1115	AND gates
74AUP1G08GS	Production	AUP	AND gate	Single 2-input ANDgate	1.1 - 3.6	CMOS	± 1.9	8.2	70	1	ultra low	-40~125	321	28.7	215	6	XSON6	SOT1202	AND gates
74AUP1G08GW	Production	AUP	AND gate	Single 2-input ANDgate	1.1 - 3.6	CMOS	± 1.9	8.2	70	1	ultra low	-40~125	309	79.2	179	5	TSSOP5	SOT353-1	AND gates
74AUP1G08GX	Production	AUP	AND gate	Single 2-input ANDgate	1.1 - 3.6	CMOS	± 1.9	8.2	70	1	ultra low	-40~125	322	90.7	191	5	X2SON5	SOT1226	AND gates
74AUP1G09GM	Production	AUP	AND gate	Single 2-input ANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	1	ultra low	-40~125	311	7.7	157	6	XSON6	SOT886	AND gates
74AUP1G09GN	Production	AUP	AND gate	Single 2-input ANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	1	ultra low	-40~125	334	22.6	207	6	XSON6	SOT1115	AND gates
74AUP1G09GS	Production	AUP	AND gate	Single 2-input ANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	1	ultra low	-40~125	321	28.7	215	6	XSON6	SOT1202	AND gates
74AUP1G09GW	Production	AUP	AND gate	Single 2-input ANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	1	ultra low	-40~125	309	79.2	179	5	TSSOP5	SOT353-1	AND gates
74AUP1G09GX	Production	AUP	AND gate	Single 2-input ANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	1	ultra low	-40~125	322	90.7	191	5	X2SON5	SOT1226	AND gates
74AUP1G11GM	Production	AUP	AND gate	Single 3-input ANDgate	1.1 - 3.6	CMOS	± 1.9	6.9	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	AND gates
74AUP1G11GN	Production	AUP	AND gate	Single 3-input ANDgate	1.1 - 3.6	CMOS	± 1.9	6.9	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	AND gates
74AUP1G11GS	Production	AUP	AND gate	Single 3-input ANDgate	1.1 - 3.6	CMOS	± 1.9	6.9	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	AND gates
74AUP1G11GW	Production	AUP	AND gate	Single 3-input ANDgate	1.1 - 3.6	CMOS	± 1.9	6.9	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	AND gates
74AUP1G32GM	Production	AUP	OR gate	Single 2-input ORgate	1.1 - 3.6	CMOS	± 1.9	7.9	70	1	ultra low	-40~125	311	7.7	157	6	XSON6	SOT886	OR gates
74AUP1G32GN	Production	AUP	OR gate	Single 2-input ORgate	1.1 - 3.6	CMOS	± 1.9	7.9	70	1	ultra low	-40~125	334	22.6	207	6	XSON6	SOT1115	OR gates
74AUP1G32GS	Production	AUP	OR gate	Single 2-input ORgate	1.1 - 3.6	CMOS	± 1.9	7.9	70	1	ultra low	-40~125	321	28.7	215	6	XSON6	SOT1202	OR gates
74AUP1G32GW	Production	AUP	OR gate	Single 2-input ORgate	1.1 - 3.6	CMOS	± 1.9	7.9	70	1	ultra low	-40~125	309	79.2	179	5	TSSOP5	SOT353-1	OR gates
74AUP1G32GX	Production	AUP	OR gate	Single 2-input ORgate	1.1 - 3.6	CMOS	± 1.9	7.9	70	1	ultra low	-40~125	322	90.7	191	5	X2SON5	SOT1226	OR gates
74AUP1G38GM	Production	AUP	NAND gate	Single 2-input NANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	1	ultra low	-40~125	311	7.7	157	6	XSON6	SOT886	NAND gates
74AUP1G38GN	Production	AUP	NAND gate	Single 2-input NANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	1	ultra low	-40~125	334	22.6	207	6	XSON6	SOT1115	NAND gates
74AUP1G38GS	Production	AUP	NAND gate	Single 2-input NANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	1	ultra low	-40~125	321	28.7	215	6	XSON6	SOT1202	NAND gates
74AUP1G38GW	Production	AUP	NAND gate	Single 2-input NANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	1	ultra low	-40~125	309	79.2	179	5	TSSOP5	SOT353-1	NAND gates
74AUP1G38GX	Production	AUP	NAND gate	Single 2-input NANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	1	ultra low	-40~125	322	90.7	191	5	X2SON5	SOT1226	NAND gates
74AUP1G57GM	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74AUP1G57GN	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74AUP1G57GS	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74AUP1G57GW	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Configurable gates;Schmitt-trigger
74AUP1G57GX	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125				6	X2SON6	SOT1255	Configurable gates;Schmitt-trigger
74AUP1G58GM	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74AUP1G58GN	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74AUP1G58GS	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74AUP1G58GW	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Configurable gates;Schmitt-trigger
74AUP1G58GX	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125				6	X2SON6	SOT1255	Configurable gates;Schmitt-trigger
74AUP1G86GM	Production	AUP	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate	1.1 - 3.6	CMOS	± 1.9	9	70	1	ultra low	-40~125	311	7.7	157	6	XSON6	SOT886	EXCLUSIVE-OR gates
74AUP1G86GN	Production	AUP	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate	1.1 - 3.6	CMOS	± 1.9	9	70	1	ultra low	-40~125	334	22.6	207	6	XSON6	SOT1115	EXCLUSIVE-OR gates
74AUP1G86GS	Production	AUP	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate	1.1 - 3.6	CMOS	± 1.9	9	70	1	ultra low	-40~125	321	28.7	215	6	XSON6	SOT1202	EXCLUSIVE-OR gates
74AUP1G86GW	Production	AUP	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate	1.1 - 3.6	CMOS	± 1.9	9	70	1	ultra low	-40~125	309	79.2	179	5	TSSOP5	SOT353-1	EXCLUSIVE-OR gates
74AUP1G86GX	Production	AUP	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate	1.1 - 3.6	CMOS	± 1.9	9	70	1	ultra low	-40~125	322	90.7	191	5	X2SON5	SOT1226	EXCLUSIVE-OR gates
74AUP1G97GM	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74AUP1G97GN	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74AUP1G97GS	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74AUP1G97GW	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Configurable gates;Schmitt-trigger
74AUP1G97GX	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125				6	X2SON6	SOT1255	Configurable gates;Schmitt-trigger
74AUP1G97UK	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125				6	WLCSP6	SOT1454-1	Configurable gates;Schmitt-trigger
74AUP1G98GM	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.9	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74AUP1G98GN	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.9	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74AUP1G98GS	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.9	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74AUP1G98GW	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.9	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Configurable gates;Schmitt-trigger
74AUP1G98GX	Production	AUP	Configurable gate	Configurable gate;Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.9	70	1	ultra low	-40~125				6	X2SON6	SOT1255	Configurable gates;Schmitt-trigger
74AUP1G132GM	Production	AUP	NAND gate	Single 2-input NANDgate Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	10	70	1	ultra low	-40~125	311	7.7	157	6	XSON6	SOT886	NAND gates
74AUP1G132GN	Production	AUP	NAND gate	Single 2-input NANDgate Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	10	70	1	ultra low	-40~125	334	22.6	207	6	XSON6	SOT1115	NAND gates
74AUP1G132GS	Production	AUP	NAND gate	Single 2-input NANDgate Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	10	70	1	ultra low	-40~125	321	28.7	215	6	XSON6	SOT1202	NAND gates
74AUP1G132GW	Production	AUP	NAND gate	Single 2-input NANDgate Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	10	70	1	ultra low	-40~125	309	79.2	179	5	TSSOP5	SOT353-1	NAND gates
74AUP1G132GX	Production	AUP	NAND gate	Single 2-input NANDgate Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	10	70	1	ultra low	-40~125	322	90.7	191	5	X2SON5	SOT1226	NAND gates
74AUP1G332GM	Production	AUP	OR gate	Single 3-input ORgate	1.1 - 3.6	CMOS	± 1.9	6.8	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	OR gates
74AUP1G332GN	Production	AUP	OR gate	Single 3-input ORgate	1.1 - 3.6	CMOS	± 1.9	6.8	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	OR gates
74AUP1G332GS	Production	AUP	OR gate	Single 3-input ORgate	1.1 - 3.6	CMOS	± 1.9	6.8	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	OR gates
74AUP1G332GW	Production	AUP	OR gate	Single 3-input ORgate	1.1 - 3.6	CMOS	± 1.9	6.8	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	OR gates
74AUP1G386GM	Production	AUP	EXCLUSIVE-OR gate	Single 3-inputEXCLUSIVE-OR gate	1.1 - 3.6	CMOS	± 1.9	8.6	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	EXCLUSIVE-OR gates
74AUP1G386GN	Production	AUP	EXCLUSIVE-OR gate	Single 3-inputEXCLUSIVE-OR gate	1.1 - 3.6	CMOS	± 1.9	8.6	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	EXCLUSIVE-OR gates
74AUP1G386GS	Production	AUP	EXCLUSIVE-OR gate	Single 3-inputEXCLUSIVE-OR gate	1.1 - 3.6	CMOS	± 1.9	8.6	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	EXCLUSIVE-OR gates
74AUP1G386GW	Production	AUP	EXCLUSIVE-OR gate	Single 3-inputEXCLUSIVE-OR gate	1.1 - 3.6	CMOS	± 1.9	8.6	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	EXCLUSIVE-OR gates
74AUP1G885DC	Production	AUP	Combination gate	Dual function gate	1.1 - 3.6	CMOS	± 1.9	7.6	70	1	ultra low	-40~125	203	34.1	113	8	VSSOP8	SOT765-1	Combination
74AUP1G885GN	Production	AUP	Combination gate	Dual function gate	1.1 - 3.6	CMOS	± 1.9	7.6	70	1	ultra low	-40~125	238	10.6	148	8	XSON8	SOT1116	Combination
74AUP1G885GS	Production	AUP	Combination gate	Dual function gate	1.1 - 3.6	CMOS	± 1.9	7.6	70	1	ultra low	-40~125	276	10.8	146	8	XSON8	SOT1203	Combination
74AUP1G885GT	Production	AUP	Combination gate	Dual function gate	1.1 - 3.6	CMOS	± 1.9	7.6	70	1	ultra low	-40~125	327	6.1	157	8	XSON8	SOT833-1	Combination
74AUP1G0832GM	Production	AUP	Combination gate	Single 3-input AND-ORgate	1.1 - 3.6	CMOS	± 1.9	6.7	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Combination
74AUP1G0832GN	Production	AUP	Combination gate	Single 3-input AND-ORgate	1.1 - 3.6	CMOS	± 1.9	6.7	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Combination
74AUP1G0832GS	Production	AUP	Combination gate	Single 3-input AND-ORgate	1.1 - 3.6	CMOS	± 1.9	6.7	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Combination
74AUP1G0832GW	Production	AUP	Combination gate	Single 3-input AND-ORgate	1.1 - 3.6	CMOS	± 1.9	6.7	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Combination
74AUP1G3208GM	Production	AUP	Combination gate	Single 3-input OR-ANDgate	1.1 - 3.6	CMOS	± 1.9	7.4	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Combination
74AUP1G3208GN	Production	AUP	Combination gate	Single 3-input OR-ANDgate	1.1 - 3.6	CMOS	± 1.9	7.4	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Combination
74AUP1G3208GS	Production	AUP	Combination gate	Single 3-input OR-ANDgate	1.1 - 3.6	CMOS	± 1.9	7.4	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Combination
74AUP1G3208GW	Production	AUP	Combination gate	Single 3-input OR-ANDgate	1.1 - 3.6	CMOS	± 1.9	7.4	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Combination
74AUP1G3208GX	Production	AUP	Combination gate	Single 3-input OR-ANDgate	1.1 - 3.6	CMOS	± 1.9	7.4	70	1	ultra low	-40~125				6	X2SON6	SOT1255	Combination
74AUP1T00GW	Production	AUP	NAND gate	2-input single supplytranslating NAND gate	2.3 - 3.6	CMOS	± 1.9	8.7		1	ultra low	-40~125	316	85.8	186	5	TSSOP5	SOT353-1	Levelshifters/translators
74AUP1T00GX	Production	AUP	NAND gate	2-input single supplytranslating NAND gate	2.3 - 3.6	CMOS	± 1.9	8.7		1	ultra low	-40~125	316	85.8	186	5	X2SON5	SOT1226	Levelshifters/translators
74AUP1T02GW	Production	AUP	NOR gate	2-input single supplytranslating NOR gate	2.3 - 3.6	CMOS	± 1.9	8.7		1	ultra low	-40~125	316	85.8	186	5	TSSOP5	SOT353-1	Levelshifters/translators
74AUP1T02GX	Production	AUP	NOR gate	2-input single supplytranslating NOR gate	2.3 - 3.6	CMOS	± 1.9	8.7		1	ultra low	-40~125	316	85.8	186	5	X2SON5	SOT1226	Levelshifters/translators
74AUP1T08GW	Production	AUP	AND gate	2-input single supplytranslating AND gate	2.3 - 3.6	CMOS	± 1.9	8.7		1	ultra low	-40~125	316	85.8	186	5	TSSOP5	SOT353-1	Levelshifters/translators
74AUP1T08GX	Production	AUP	AND gate	2-input single supplytranslating AND gate	2.3 - 3.6	CMOS	± 1.9	8.7		1	ultra low	-40~125	316	85.8	186	5	X2SON5	SOT1226	Levelshifters/translators
74AUP1T32GW	Production	AUP	OR gate	2-input single supplytranslating OR gate	2.3 - 3.6	CMOS	± 1.9	8.7		1	ultra low	-40~125	316	85.8	186	5	TSSOP5	SOT353-1	Levelshifters/translators
74AUP1T32GX	Production	AUP	OR gate	2-input single supplytranslating OR gate	2.3 - 3.6	CMOS	± 1.9	8.7		1	ultra low	-40~125	316	85.8	186	5	X2SON5	SOT1226	Levelshifters/translators
74AUP1T57GM	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74AUP1T57GN	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74AUP1T57GS	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74AUP1T57GW	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Configurable gates;Schmitt-trigger
74AUP1T58GM	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74AUP1T58GN	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74AUP1T58GS	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74AUP1T58GW	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Configurable gates;Schmitt-trigger
74AUP1T86GW	Production	AUP	EXCLUSIVE-OR gate	2-input single supplytranslating X-OR gate	2.3 - 3.6	CMOS	± 1.9	8.7		1	ultra low	-40~125	316	85.8	186	5	TSSOP5	SOT353-1	Levelshifters/translators
74AUP1T86GX	Production	AUP	EXCLUSIVE-OR gate	2-input single supplytranslating X-OR gate	2.3 - 3.6	CMOS	± 1.9	8.7		1	ultra low	-40~125	316	85.8	186	5	X2SON5	SOT1226	Levelshifters/translators
74AUP1T87GW	Production	AUP	EXCLUSIVE-NOR gate	2-input single supplytranslating X-NOR gate		CMOS	± 1.9	8.7		1	ultra low	-40~125	316	85.8	186	5	TSSOP5	SOT353-1	Levelshifters/translators
74AUP1T87GX	Production	AUP	EXCLUSIVE-NOR gate	2-input single supplytranslating X-NOR gate		CMOS	± 1.9	8.7		1	ultra low	-40~125	316	85.8	186	5	X2SON5	SOT1226	Levelshifters/translators
74AUP1T97GM	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74AUP1T97GN	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74AUP1T97GS	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74AUP1T97GW	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Configurable gates;Schmitt-trigger
74AUP1T97GX	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	316	85.8	186	6	X2SON6	SOT1255	Configurable gates;Schmitt-trigger
74AUP1T97UK	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	316	85.8	186	6	WLCSP6	SOT1454-1	Configurable gates;Schmitt-trigger
74AUP1T98GM	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74AUP1T98GN	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74AUP1T98GS	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74AUP1T98GW	Production	AUP	Configurable gate	Configurable gatewith voltage level translation	2.3 - 3.6	CMOS	± 1.9	8.7	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Configurable gates;Schmitt-trigger
74AUP1Z04GM	Production	AUP	Combination gate	Crystal driver withenable and internal resistor	1.1 - 3.6	CMOS	± 1.9	5.6	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Combination
74AUP1Z04GN	Production	AUP	Combination gate	Crystal driver withenable and internal resistor	1.1 - 3.6	CMOS	± 1.9	5.6	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Combination
74AUP1Z04GS	Production	AUP	Combination gate	Crystal driver withenable and internal resistor	1.1 - 3.6	CMOS	± 1.9	5.6	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Combination
74AUP1Z04GW	Production	AUP	Combination gate	Crystal driver withenable and internal resistor	1.1 - 3.6	CMOS	± 1.9	5.6	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Combination
74AUP1Z125GM	Production	AUP	Combination gate	Crystal driver withenable and internal resistor (3-state)	1.1 - 3.6	CMOS	± 1.9	4.7	70	1	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Combination
74AUP1Z125GN	Production	AUP	Combination gate	Crystal driver withenable and internal resistor (3-state)	1.1 - 3.6	CMOS	± 1.9	4.7	70	1	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Combination
74AUP1Z125GS	Production	AUP	Combination gate	Crystal driver withenable and internal resistor (3-state)	1.1 - 3.6	CMOS	± 1.9	4.7	70	1	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Combination
74AUP1Z125GW	Production	AUP	Combination gate	Crystal driver withenable and internal resistor (3-state)	1.1 - 3.6	CMOS	± 1.9	4.7	70	1	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Combination
74AUP2G00DC	Production	AUP	NAND gates	Dual 2-input NANDgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	2	ultra low	-40~125	203	34.1	113	8	VSSOP8	SOT765-1	NAND gates
74AUP2G00GN	Production	AUP	NAND gates	Dual 2-input NANDgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	2	ultra low	-40~125	238	10.6	148	8	XSON8	SOT1116	NAND gates
74AUP2G00GS	Production	AUP	NAND gates	Dual 2-input NANDgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	2	ultra low	-40~125	276	10.8	146	8	XSON8	SOT1203	NAND gates
74AUP2G00GT	Production	AUP	NAND gates	Dual 2-input NANDgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	2	ultra low	-40~125	327	6.1	157	8	XSON8	SOT833-1	NAND gates
74AUP2G00GX	Production	AUP	NAND gates	Dual 2-input NANDgate	1.1 - 3.6	CMOS	± 1.9	8.3	70	2	ultra low	-40~125				8	X2SON8	SOT1233	NAND gates
74AUP2G02DC	Production	AUP	NOR gates	Dual 2-input NOR gate	1.1 - 3.6	CMOS	± 1.9	8.3	70	2	ultra low	-40~125	203	34.1	113	8	VSSOP8	SOT765-1	NOR gates
74AUP2G02GN	Production	AUP	NOR gates	Dual 2-input NOR gate	1.1 - 3.6	CMOS	± 1.9	8.3	70	2	ultra low	-40~125	238	10.6	148	8	XSON8	SOT1116	NOR gates
74AUP2G02GS	Production	AUP	NOR gates	Dual 2-input NOR gate	1.1 - 3.6	CMOS	± 1.9	8.3	70	2	ultra low	-40~125	276	10.8	146	8	XSON8	SOT1203	NOR gates
74AUP2G02GT	Production	AUP	NOR gates	Dual 2-input NOR gate	1.1 - 3.6	CMOS	± 1.9	8.3	70	2	ultra low	-40~125	327	6.1	157	8	XSON8	SOT833-1	NOR gates
74AUP2G08DC	Production	AUP	AND gates	Dual 2-input AND gate	1.1 - 3.6	CMOS	± 1.9	8.2	70	2	ultra low	-40~125	203	34.1	113	8	VSSOP8	SOT765-1	AND gates
74AUP2G08GN	Production	AUP	AND gates	Dual 2-input AND gate	1.1 - 3.6	CMOS	± 1.9	8.2	70	2	ultra low	-40~125	238	10.6	148	8	XSON8	SOT1116	AND gates
74AUP2G08GS	Production	AUP	AND gates	Dual 2-input AND gate	1.1 - 3.6	CMOS	± 1.9	8.2	70	2	ultra low	-40~125	276	10.8	146	8	XSON8	SOT1203	AND gates
74AUP2G08GT	Production	AUP	AND gates	Dual 2-input AND gate	1.1 - 3.6	CMOS	± 1.9	8.2	70	2	ultra low	-40~125	327	6.1	157	8	XSON8	SOT833-1	AND gates
74AUP2G08GX	Production	AUP	AND gates	Dual 2-input AND gate	1.1 - 3.6	CMOS	± 1.9	8.2	70	2	ultra low	-40~125				8	X2SON8	SOT1233	AND gates
74AUP2G32DC	Production	AUP	OR gates	Dual 2-input OR gate	1.1 - 3.6	CMOS	± 1.9	7.9	70	2	ultra low	-40~125	203	34.1	113	8	VSSOP8	SOT765-1	OR gates
74AUP2G32GN	Production	AUP	OR gates	Dual 2-input OR gate	1.1 - 3.6	CMOS	± 1.9	7.9	70	2	ultra low	-40~125	238	10.6	148	8	XSON8	SOT1116	OR gates
74AUP2G32GS	Production	AUP	OR gates	Dual 2-input OR gate	1.1 - 3.6	CMOS	± 1.9	7.9	70	2	ultra low	-40~125	276	10.8	146	8	XSON8	SOT1203	OR gates
74AUP2G32GT	Production	AUP	OR gates	Dual 2-input OR gate	1.1 - 3.6	CMOS	± 1.9	7.9	70	2	ultra low	-40~125	327	6.1	157	8	XSON8	SOT833-1	OR gates
74AUP2G32GX	Production	AUP	OR gates	Dual 2-input OR gate	1.1 - 3.6	CMOS	± 1.9	7.9	70	2	ultra low	-40~125				8	X2SON8	SOT1233	OR gates
74AUP2G38DC	Production	AUP	NAND gates	Dual 2-input NANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	2	ultra low	-40~125	203	34.1	113	8	VSSOP8	SOT765-1	NAND gates
74AUP2G38GN	Production	AUP	NAND gates	Dual 2-input NANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	2	ultra low	-40~125	238	10.6	148	8	XSON8	SOT1116	NAND gates
74AUP2G38GS	Production	AUP	NAND gates	Dual 2-input NANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	2	ultra low	-40~125	276	10.8	146	8	XSON8	SOT1203	NAND gates
74AUP2G38GT	Production	AUP	NAND gates	Dual 2-input NANDgate; open-drain	1.1 - 3.6	CMOS	1.9	8.5	70	2	ultra low	-40~125	327	6.1	157	8	XSON8	SOT833-1	NAND gates
74AUP2G57DP	Production	AUP	Configurable gates	Dual Configurablegate; Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	2	ultra low	-40~125	120	30		10	TSSOP10	SOT552-1	Configurable gates;Schmitt-trigger
74AUP2G57GU	Production	AUP	Configurable gates	Dual configurablegate; Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	2	ultra low	-40~125	142	48		10	XQFN10	SOT1160-1	Configurable gates;Schmitt-trigger
74AUP2G58DP	Production	AUP	Configurable gates	Dual Configurablegate; Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	2	ultra low	-40~125	120	30		10	TSSOP10	SOT552-1	Configurable gates;Schmitt-trigger
74AUP2G58GU	Production	AUP	Configurable gates	Dual configurablegate; Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	2	ultra low	-40~125	142	48		10	XQFN10	SOT1160-1	Configurable gates;Schmitt-trigger
74AUP2G86DC	Production	AUP	EXCLUSIVE-OR gates	Dual 2-inputEXCLUSIVE-OR gate	1.1 - 3.6	CMOS	± 1.9	9	70	2	ultra low	-40~125	203	34.1	113	8	VSSOP8	SOT765-1	EXCLUSIVE-OR gates
74AUP2G86GN	Production	AUP	EXCLUSIVE-OR gates	Dual 2-inputEXCLUSIVE-OR gate	1.1 - 3.6	CMOS	± 1.9	9	70	2	ultra low	-40~125	238	10.6	148	8	XSON8	SOT1116	EXCLUSIVE-OR gates
74AUP2G86GS	Production	AUP	EXCLUSIVE-OR gates	Dual 2-inputEXCLUSIVE-OR gate	1.1 - 3.6	CMOS	± 1.9	9	70	2	ultra low	-40~125	276	10.8	146	8	XSON8	SOT1203	EXCLUSIVE-OR gates
74AUP2G86GT	Production	AUP	EXCLUSIVE-OR gates	Dual 2-inputEXCLUSIVE-OR gate	1.1 - 3.6	CMOS	± 1.9	9	70	2	ultra low	-40~125	327	6.1	157	8	XSON8	SOT833-1	EXCLUSIVE-OR gates
74AUP2G97DP	Production	AUP	Configurable gates	Dual Configurablegate; Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	2	ultra low	-40~125	120	30		10	TSSOP10	SOT552-1	Configurable gates;Schmitt-trigger
74AUP2G97GU	Production	AUP	Configurable gates	Dual configurablegate; Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	8.7	70	2	ultra low	-40~125	142	48		10	XQFN10	SOT1160-1	Configurable gates;Schmitt-trigger
74AUP2G98DP	Production	AUP	Configurable gates	Dual Configurablegate; Schmitt trigger	1.1 - 3.6	CMOS	± 1.9	8.9	70	2	ultra low	-40~125	120	30		10	TSSOP10	SOT552-1	Configurable gates;Schmitt-trigger
74AUP2G98GU	Production	AUP	Configurable gates	Dual configurablegate; Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	8.9	70	2	ultra low	-40~125	142	48		10	XQFN10	SOT1160-1	Configurable gates;Schmitt-trigger
74AUP2G132DC	Production	AUP	NAND gates	Dual 2-input NANDgate Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	10	70	2	ultra low	-40~125	203	34.1	113	8	VSSOP8	SOT765-1	Schmitt-triggers
74AUP2G132GN	Production	AUP	NAND gates	Dual 2-input NANDgate Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	10	70	2	ultra low	-40~125	238	10.6	148	8	XSON8	SOT1116	Schmitt-triggers
74AUP2G132GS	Production	AUP	NAND gates	Dual 2-input NANDgate Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	10	70	2	ultra low	-40~125	276	10.8	146	8	XSON8	SOT1203	Schmitt-triggers
74AUP2G132GT	Production	AUP	NAND gates	Dual 2-input NANDgate Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	10	70	2	ultra low	-40~125	327	6.1	157	8	XSON8	SOT833-1	Schmitt-triggers
74AUP2G132GX	Production	AUP	NAND gates	Dual 2-input NANDgate Schmitt-trigger	1.1 - 3.6	CMOS	± 1.9	10	70	2	ultra low	-40~125				8	X2SON8	SOT1233	Schmitt-triggers
74AUP2G0604GM	Production	AUP	Combination gates	Inverter withopen-drain and inverter	1.1 - 3.6	CMOS	± 1.9	4	70	2	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Combination
74AUP2G0604GN	Production	AUP	Combination gates	Inverter withopen-drain and inverter	1.1 - 3.6	CMOS	± 1.9	4	70	2	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Combination
74AUP2G0604GS	Production	AUP	Combination gates	Inverter withopen-drain and inverter	1.1 - 3.6	CMOS	± 1.9	4	70	2	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Combination
74AUP2G0604GW	Production	AUP	Combination gates	Inverter withopen-drain and inverter	1.1 - 3.6	CMOS	± 1.9	4	70	2	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Combination
74AUP2G3404GM	Production	AUP	Combination gates	Buffer and inverter	1.1 - 3.6	CMOS	± 1.9	4	70	2	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Combination
74AUP2G3404GN	Production	AUP	Combination gates	Buffer and inverter	1.1 - 3.6	CMOS	± 1.9	4	70	2	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Combination
74AUP2G3404GS	Production	AUP	Combination gates	Buffer and inverter	1.1 - 3.6	CMOS	± 1.9	4	70	2	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Combination
74AUP2G3404GW	Production	AUP	Combination gates	Buffer and inverter	1.1 - 3.6	CMOS	± 1.9	4	70	2	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Combination
74AUP2G3407GM	Production	AUP	Combination gates	Buffer and bufferwith open-drain	1.1 - 3.6	CMOS	± 1.9	4.1	70	2	ultra low	-40~125	290	6.5	145	6	XSON6	SOT886	Combination
74AUP2G3407GN	Production	AUP	Combination gates	Buffer and bufferwith open-drain	1.1 - 3.6	CMOS	± 1.9	4.1	70	2	ultra low	-40~125	275	11.7	171	6	XSON6	SOT1115	Combination
74AUP2G3407GS	Production	AUP	Combination gates	Buffer and bufferwith open-drain	1.1 - 3.6	CMOS	± 1.9	4.1	70	2	ultra low	-40~125	272	14.8	177	6	XSON6	SOT1202	Combination
74AUP2G3407GW	Production	AUP	Combination gates	Buffer and bufferwith open-drain	1.1 - 3.6	CMOS	± 1.9	4.1	70	2	ultra low	-40~125	264	38.6	153	6	TSSOP6	SOT363	Combination
74AUP3G0434DC	Production	AUP	Combination gates	Dual inverter andsingle buffer	1.1 - 3.6	CMOS	± 1.9	4	70	3	ultra low	-40~125	203	34.1	113	8	VSSOP8	SOT765-1	Combination
74AUP3G0434GN	Production	AUP	Combination gates	Dual inverter andsingle buffer	1.1 - 3.6	CMOS	± 1.9	4	70	3	ultra low	-40~125	238	10.6	148	8	XSON8	SOT1116	Combination
74AUP3G0434GS	Production	AUP	Combination gates	Dual inverter andsingle buffer	1.1 - 3.6	CMOS	± 1.9	4	70	3	ultra low	-40~125	276	10.8	146	8	XSON8	SOT1203	Combination
74AUP3G0434GT	Production	AUP	Combination gates	Dual inverter andsingle buffer	1.1 - 3.6	CMOS	± 1.9	4	70	3	ultra low	-40~125	327	6.1	157	8	XSON8	SOT833-1	Combination
74AUP3G3404DC	Production	AUP	Combination gates	Dual buffer andsingle inverter	1.1 - 3.6	CMOS	± 1.9	4	70	3	ultra low	-40~125	203	34.1	113	8	VSSOP8	SOT765-1	Combination
74AUP3G3404GN	Production	AUP	Combination gates	Dual buffer andsingle inverter	1.1 - 3.6	CMOS	± 1.9	4	70	3	ultra low	-40~125	238	10.6	148	8	XSON8	SOT1116	Combination
74AUP3G3404GS	Production	AUP	Combination gates	Dual buffer andsingle inverter	1.1 - 3.6	CMOS	± 1.9	4	70	3	ultra low	-40~125	276	10.8	146	8	XSON8	SOT1203	Combination
74AUP3G3404GT	Production	AUP	Combination gates	Dual buffer andsingle inverter	1.1 - 3.6	CMOS	± 1.9	4	70	3	ultra low	-40~125	327	6.1	157	8	XSON8	SOT833-1	Combination
74AVC1T8128GS	Production	AVC	Combination gate	Single dual-supplytranslating 2-input NOR with enable	0.8 - 3.6	CMOS/LVTTL	± 12	2.4		1	very low	-40~125	280	11.5	149	8	XSON8	SOT1203	Levelshifters/translators
74AVC1T8832GS	Production	AVC	Combination gate	Single dual-supplytranslating 2-input OR with strobe	0.8 - 3.6	CMOS/LVTTL	± 12	2.4		1	very low	-40~125	280	11.5	149	8	XSON8	SOT1203	Levelshifters/translators
74AXP1G00GM	Production	AXP	NAND gate	Single 2-input NANDgate	0.7 - 2.75	CMOS	± 4.5	2.7	70	1	ultra low	-40~85	322	8.3	164	6	XSON6	SOT886	NAND gates
74AXP1G00GN	Production	AXP	NAND gate	Single 2-input NANDgate	0.7 - 2.75	CMOS	± 4.5	2.7	70	1	ultra low	-40~85	366	28.6	226	6	XSON6	SOT1115	NAND gates
74AXP1G00GS	Production	AXP	NAND gate	Single 2-input NANDgate	0.7 - 2.75	CMOS	± 4.5	2.7	70	1	ultra low	-40~85	347	36.3	235	6	XSON6	SOT1202	NAND gates
74AXP1G00GX	Production	AXP	NAND gate	Single 2-input NANDgate	0.7 - 2.75	CMOS	± 4.5	2.7	70	1	ultra low	-40~85	352	115.9	217	5	X2SON5	SOT1226	NAND gates
74AXP1G02GM	Production	AXP	NOR gate	Single 2-input NORgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	322	8.3	164	6	XSON6	SOT886	NOR gates
74AXP1G02GN	Production	AXP	NOR gate	Single 2-input NORgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	366	28.6	226	6	XSON6	SOT1115	NOR gates
74AXP1G02GS	Production	AXP	NOR gate	Single 2-input NORgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	347	36.3	235	6	XSON6	SOT1202	NOR gates
74AXP1G02GX	Production	AXP	NOR gate	Single 2-input NORgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	352	115.9	217	5	X2SON5	SOT1226	NOR gates
74AXP1G08GM	Production	AXP	AND gate	Single 2-input ANDgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	322	8.3	164	6	XSON6	SOT886	AND gates
74AXP1G08GN	Production	AXP	AND gate	Single 2-input ANDgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	366	28.6	226	6	XSON6	SOT1115	AND gates
74AXP1G08GS	Production	AXP	AND gate	Single 2-input ANDgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	347	36.3	235	6	XSON6	SOT1202	AND gates
74AXP1G08GX	Production	AXP	AND gate	Single 2-input ANDgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	352	115.9	217	5	X2SON5	SOT1226	AND gates
74AXP1G09GM	Production	AXP	AND gate	Single 2-input ANDgate with open-drain output	0.7 - 2.75	CMOS	4.5	2.6	70	1	ultra low	-40~85	322	8.3	164	6	XSON6	SOT886	AND gates
74AXP1G09GN	Production	AXP	AND gate	Single 2-input ANDgate with open-drain output	0.7 - 2.75	CMOS	4.5	2.6	70	1	ultra low	-40~85	366	28.6	226	6	XSON6	SOT1115	AND gates
74AXP1G09GS	Production	AXP	AND gate	Single 2-input ANDgate with open-drain output	0.7 - 2.75	CMOS	4.5	2.6	70	1	ultra low	-40~85	347	36.3	235	6	XSON6	SOT1202	AND gates
74AXP1G09GX	Production	AXP	AND gate	Single 2-inputAND gate with open-drain output	0.7 - 2.75	CMOS	4.5	2.6	70	1	ultra low	-40~85	352	115.9	217	5	X2SON5	SOT1226	AND gates
74AXP1G10GM	Production	AXP	NAND gate	Single 3-input NANDgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	322	8.3	164	6	XSON6	SOT886	NAND gates
74AXP1G10GN	Production	AXP	NAND gate	Single 3-input NANDgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	366	28.6	226	6	XSON6	SOT1115	NAND gates
74AXP1G10GS	Production	AXP	NAND gate	Single 3-input NANDgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	347	36.3	235	6	XSON6	SOT1202	NAND gates
74AXP1G11GM	Production	AXP	AND gate	Single 3-input ANDgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	322	8.3	164	6	XSON6	SOT886	AND gates
74AXP1G11GN	Production	AXP	AND gate	Single 3-input ANDgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	366	28.6	226	6	XSON6	SOT1115	AND gates
74AXP1G11GS	Production	AXP	AND gate	Single 3-input ANDgate	0.7 - 2.75	CMOS	± 4.5	2.6	70	1	ultra low	-40~85	347	36.3	235	6	XSON6	SOT1202	AND gates
74AXP1G32GM	Production	AXP	OR gate	Single 2-input ORgate	0.7 - 2.75	CMOS	± 4.5	2.5	70	1	ultra low	-40~85	322	8.3	164	6	XSON6	SOT886	OR gates
74AXP1G32GN	Production	AXP	OR gate	Single 2-input ORgate	0.7 - 2.75	CMOS	± 4.5	2.5	70	1	ultra low	-40~85	366	28.6	226	6	XSON6	SOT1115	OR gates
74AXP1G32GS	Production	AXP	OR gate	Single 2-input ORgate	0.7 - 2.75	CMOS	± 4.5	2.5	70	1	ultra low	-40~85	347	36.3	235	6	XSON6	SOT1202	OR gates
74AXP1G32GX	Production	AXP	OR gate	Single 2-input ORgate	0.7 - 2.75	CMOS	± 4.5	2.5	70	1	ultra low	-40~85	352	115.9	217	5	X2SON5	SOT1226	OR gates
74AXP1G57GM	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.6	70	1	ultra low	-40~85	322	8.3	164	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74AXP1G57GN	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.6	70	1	ultra low	-40~85	366	28.6	226	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74AXP1G57GS	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.6	70	1	ultra low	-40~85	347	36.3	235	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74AXP1G57GX	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.6	70	1	ultra low	-40~85				6	X2SON6	SOT1255	Configurable gates;Schmitt-trigger
74AXP1G58GM	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85	322	8.3	164	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74AXP1G58GN	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85	366	28.6	226	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74AXP1G58GS	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85	347	36.3	235	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74AXP1G58GX	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85				6	X2SON6	SOT1255	Configurable gates;Schmitt-trigger
74AXP1G86GM	Production	AXP	EXCLUSIVE-OR gate	Single 2-inputExclusive-OR gates	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85	322	8.3	164	6	XSON6	SOT886	Exclusive-OR gates
74AXP1G86GN	Production	AXP	EXCLUSIVE-OR gate	Single 2-inputExclusive-OR gates	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85	366	28.6	226	6	XSON6	SOT1115	Exclusive-OR gates
74AXP1G86GS	Production	AXP	EXCLUSIVE-OR gate	Single 2-inputExclusive-OR gates	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85	347	36.3	235	6	XSON6	SOT1202	Exclusive-OR gates
74AXP1G86GX	Production	AXP	EXCLUSIVE-OR gate	Single 2-inputExclusive-OR gates	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85	340	105	206	5	X2SON5	SOT1226	Exclusive-OR gates
74AXP1G97GM	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85	322	8.3	164	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74AXP1G97GN	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85	366	28.6	226	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74AXP1G97GS	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85	347	36.3	235	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74AXP1G97GX	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85				6	X2SON6	SOT1255	Configurable gates;Schmitt-trigger
74AXP1G98GM	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85	322	8.3	164	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74AXP1G98GN	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85	366	28.6	226	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74AXP1G98GS	Production	AXP	Configurable gate	Configurable gate;Schmitt trigger	0.7 - 2.75	CMOS	± 4.5	4.5	70	1	ultra low	-40~85	347	36.3	235	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74AXP1T57GT	Production	AXP	Configurable gate	Single dual-supplytranslating configurable gate; Schmitt-trigger inputs	0.7 - 2.75/ 1.2 - 5.5	CMOS	± 12	4.8	70	1	ultra low	-40~125	357	7.8	178	8	XSON8	SOT833-1	Levelshifters/translators
74AXP1T57GX	Production	AXP	Configurable gate	Single dual-supplytranslating configurable gate; Schmitt-trigger inputs	0.7 - 2.75/ 1.2 - 5.5	CMOS	± 12	4.8	70	1	ultra low	-40~125				8	X2SON8	SOT1233	Levelshifters/translators
74HC21D	Production	HC(T)	AND gates	Dual 4-input AND gate	2.0 - 6.0	CMOS	± 5.2	10	36	2	low	-40~125	83	3.4	40	14	SO14	SOT108-1	AND gates
74HC21PW	Production	HC(T)	AND gates	Dual 4-input AND gate	2.0 - 6.0	CMOS	± 5.2	10	36	2	low	-40~125	124	2.1	48.3	14	TSSOP14	SOT402-1	AND gates
74HC1G00GV	Production	HC(T)	NAND gate	Single 2-input NANDgate	2.0 - 6.0	CMOS	± 2.6	7	36	1	low	-40~125	220	33	131	5	TSOP5	SOT753	NAND gates
74HC1G00GW	Production	HC(T)	NAND gate	Single 2-input NANDgate	2.0 - 6.0	CMOS	± 2.6	7	36	1	low	-40~125	261	39.3	138	5	TSSOP5	SOT353-1	NAND gates
74HCT1G00GV	Production	HC(T)	NAND gate	Single 2-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 2	10	36	1	low	-40~125	220	33	131	5	TSOP5	SOT753	NAND gates
74HCT1G00GW	Production	HC(T)	NAND gate	Single 2-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 2	10	36	1	low	-40~125	261	39.3	138	5	TSSOP5	SOT353-1	NAND gates
74HC1G02GV	Production	HC(T)	NOR gate	Single 2-input NORgate	2.0 - 6.0	CMOS	± 2.6	7	36	1	low	-40~125	220	33	131	5	TSOP5	SOT753	NOR gates
74HC1G02GW	Production	HC(T)	NOR gate	Single 2-input NORgate	2.0 - 6.0	CMOS	± 2.6	7	36	1	low	-40~125	261	39.3	138	5	TSSOP5	SOT353-1	NOR gates
74HCT1G02GV	Production	HC(T)	NOR gate	Single 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 2	9	36	1	low	-40~125	220	33	131	5	TSOP5	SOT753	NOR gates
74HCT1G02GW	Production	HC(T)	NOR gate	Single 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 2	9	36	1	low	-40~125	261	39.3	138	5	TSSOP5	SOT353-1	NOR gates
74HC1G08GV	Production	HC(T)	AND gate	Single 2-input ANDgate	2.0 - 6.0	CMOS	± 5.2	7	36	1	low	-40~125	220	33	131	5	TSOP5	SOT753	AND gates
74HC1G08GW	Production	HC(T)	AND gate	Single 2-input ANDgate	2.0 - 6.0	CMOS	± 5.2	7	36	1	low	-40~125	261	39.3	138	5	TSSOP5	SOT353-1	AND gates
74HCT1G08GV	Production	HC(T)	AND gate	Single 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 2	11	36	1	low	-40~125	220	33	131	5	TSOP5	SOT753	AND gates
74HCT1G08GW	Production	HC(T)	AND gate	Single 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 2	11	36	1	low	-40~125	261	39.3	138	5	TSSOP5	SOT353-1	AND gates
74HC1G32GV	Production	HC(T)	OR gate	Single 2-input ORgate	2.0 - 6.0	CMOS	± 2.6	8	36	1	low	-40~125	220	33	131	5	TSOP5	SOT753	OR gates
74HC1G32GW	Production	HC(T)	OR gate	Single 2-input ORgate	2.0 - 6.0	CMOS	± 2.6	8	36	1	low	-40~125	261	39.3	138	5	TSSOP5	SOT353-1	OR gates
74HCT1G32GV	Production	HC(T)	OR gate	Single 2-input ORgate; TTL enabled	4.5 - 5.5	TTL	± 2	10	36	1	low	-40~125	220	33	131	5	TSOP5	SOT753	OR gates
74HCT1G32GW	Production	HC(T)	OR gate	Single 2-input ORgate; TTL enabled	4.5 - 5.5	TTL	± 2	10	36	1	low	-40~125	261	39.3	138	5	TSSOP5	SOT353-1	OR gates
74HC1G86GV	Production	HC(T)	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate	2.0 - 6.0	CMOS	± 2.6	9	36	1	low	-40~125	220	33	131	5	TSOP5	SOT753	EXCLUSIVE-OR gates
74HC1G86GW	Production	HC(T)	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate	2.0 - 6.0	CMOS	± 2.6	9	36	1	low	-40~125	261	39.3	138	5	TSSOP5	SOT353-1	EXCLUSIVE-OR gates
74HCT1G86GV	Production	HC(T)	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate; TTL enabled	4.5 - 5.5	TTL	± 2	10	36	1	low	-40~125	220	33	131	5	TSOP5	SOT753	EXCLUSIVE-OR gates
74HCT1G86GW	Production	HC(T)	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate; TTL enabled	4.5 - 5.5	TTL	± 2	10	36	1	low	-40~125	261	39.3	138	5	TSSOP5	SOT353-1	EXCLUSIVE-OR gates
74HC2G00DC	Production	HC(T)	NAND gates	Dual 2-input NANDgate	2.0 - 6.0	CMOS	± 5.2	9	36	2	low	-40~125	204	35.1	115	8	VSSOP8	SOT765-1	NAND gates
74HC2G00DP	Production	HC(T)	NAND gates	Dual 2-input NANDgate	2.0 - 6.0	CMOS	± 5.2	9	36	2	low	-40~125	216	20.5	106	8	TSSOP8	SOT505-2	NAND gates
74HCT2G00DC	Production	HC(T)	NAND gates	Dual 2-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 4	12	36	2	low	-40~125	204	35.1	115	8	VSSOP8	SOT765-1	NAND gates
74HCT2G00DP	Production	HC(T)	NAND gates	Dual 2-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 4	12	36	2	low	-40~125	216	20.5	106	8	TSSOP8	SOT505-2	NAND gates
74HC2G02DC	Production	HC(T)	NOR gates	Dual 2-input NOR gate	2.0 - 6.0	CMOS	± 5.2	9	36	2	low	-40~125	204	35.1	115	8	VSSOP8	SOT765-1	NOR gates
74HC2G02DP	Production	HC(T)	NOR gates	Dual 2-input NOR gate	2.0 - 6.0	CMOS	± 5.2	9	36	2	low	-40~125	216	20.5	106	8	TSSOP8	SOT505-2	NOR gates
74HCT2G02DC	Production	HC(T)	NOR gates	Dual 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 4	12	36	2	low	-40~125	204	35.1	115	8	VSSOP8	SOT765-1	NOR gates
74HCT2G02DP	Production	HC(T)	NOR gates	Dual 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 4	12	36	2	low	-40~125	216	20.5	106	8	TSSOP8	SOT505-2	NOR gates
74HC2G08DC	Production	HC(T)	AND gates	Dual 2-input AND gate	2.0 - 6.0	CMOS	± 5.2	9	36	2	low	-40~125	204	35.1	115	8	VSSOP8	SOT765-1	AND gates
74HC2G08DP	Production	HC(T)	AND gates	Dual 2-input AND gate	2.0 - 6.0	CMOS	± 5.2	9	36	2	low	-40~125	216	20.5	106	8	TSSOP8	SOT505-2	AND gates
74HCT2G08DC	Production	HC(T)	AND gates	Dual 2-Input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 4	14	36	2	low	-40~125	204	35.1	115	8	VSSOP8	SOT765-1	AND gates
74HCT2G08DP	Production	HC(T)	AND gates	Dual 2-Input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 4	14	36	2	low	-40~125	216	20.5	106	8	TSSOP8	SOT505-2	AND gates
74HC2G32DC	Production	HC(T)	OR gates	Dual 2-input OR gate	2.0 - 6.0	CMOS	± 5.2	9	36	2	low	-40~125	204	35.1	115	8	VSSOP8	SOT765-1	OR gates
74HC2G32DP	Production	HC(T)	OR gates	Dual 2-input OR gate	2.0 - 6.0	CMOS	± 5.2	9	36	2	low	-40~125	216	20.5	106	8	TSSOP8	SOT505-2	OR gates
74HCT2G32DC	Production	HC(T)	OR gates	Dual 2-input OR gate;TTL enabled	4.5 - 5.5	TTL	± 4	13	36	2	low	-40~125	204	35.1	115	8	VSSOP8	SOT765-1	OR gates
74HCT2G32DP	Production	HC(T)	OR gates	Dual 2-input OR gate;TTL enabled	4.5 - 5.5	TTL	± 4	13	36	2	low	-40~125	216	20.5	106	8	TSSOP8	SOT505-2	OR gates
74HC2G86DC	Production	HC(T)	EXCLUSIVE-OR gates	Dual 2-inputEXCLUSIVE-OR gate	2.0 - 6.0	CMOS	± 5.2	9	36	2	low	-40~125	209	38.4	120	8	VSSOP8	SOT765-1	EXCLUSIVE-OR gates
74HC2G86DP	Production	HC(T)	EXCLUSIVE-OR gates	Dual 2-inputEXCLUSIVE-OR gate	2.0 - 6.0	CMOS	± 5.2	9	36	2	low	-40~125	224	22.5	108	8	TSSOP8	SOT505-2	EXCLUSIVE-OR gates
74HCT2G86DC	Production	HC(T)	EXCLUSIVE-OR gates	Dual 2-inputEXCLUSIVE-OR gate; TTL enabled	4.5 - 5.5	TTL	± 4	11	36	2	low	-40~125	209	38.4	120	8	VSSOP8	SOT765-1	EXCLUSIVE-OR gates
74HC00BQ	Production	HC(T)	NAND gates	Quad 2-input NANDgate	2.0 - 6.0	CMOS	± 5.2	7	36	4	low	-40~125	107	21.7	75	14	DHVQFN14	SOT762-1	NAND gates
74HC00D	Production	HC(T)	NAND gates	Quad 2-input NANDgate	2.0 - 6.0	CMOS	± 5.2	7	36	4	low	-40~125	109	20.9	68	14	SO14	SOT108-1	NAND gates
74HC00PW	Production	HC(T)	NAND gates	Quad 2-input NANDgate	2.0 - 6.0	CMOS	± 5.2	7	36	4	low	-40~125	142	8.1	68	14	TSSOP14	SOT402-1	NAND gates
74HCT00BQ	Production	HC(T)	NAND gates	Quad 2-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 4	10	36	4	low	-40~125	107	21.7	75	14	DHVQFN14	SOT762-1	NAND gates
74HCT00D	Production	HC(T)	NAND gates	Quad 2-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 4	10	36	4	low	-40~125	109	20.9	68	14	SO14	SOT108-1	NAND gates
74HCT00PW	Production	HC(T)	NAND gates	Quad 2-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 4	10	36	4	low	-40~125	142	8.1	68	14	TSSOP14	SOT402-1	NAND gates
74HC02BQ	Production	HC(T)	NOR gates	Quad 2-input NOR gate	2.0 - 6.0	CMOS	± 5.2	7	36	4	low	-40~125	107	21.7	75	14	DHVQFN14	SOT762-1	NOR gates
74HC02D	Production	HC(T)	NOR gates	Quad 2-input NORgate	2.0 - 6.0	CMOS	± 5.2	7	36	4	low	-40~125	109	20.9	68	14	SO14	SOT108-1	NOR gates
74HC02PW	Production	HC(T)	NOR gates	Quad 2-input NOR gate	2.0 - 6.0	CMOS	± 5.2	7	36	4	low	-40~125	142	8.1	68	14	TSSOP14	SOT402-1	NOR gates
74HCT02BQ	Production	HC(T)	NOR gates	Quad 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 4	9	36	4	low	-40~125	107	21.7	75	14	DHVQFN14	SOT762-1	NOR gates
74HCT02D	Production	HC(T)	NOR gates	Quad 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 4	9	36	4	low	-40~125	109	20.9	68	14	SO14	SOT108-1	NOR gates
74HCT02PW	Production	HC(T)	NOR gates	Quad 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 4	9	36	4	low	-40~125	142	8.1	68	14	TSSOP14	SOT402-1	NOR gates
74HC03D	Production	HC(T)	NAND gates	Quad 2-input NANDgate; open-drain	2.0 - 6.0	CMOS	5.2	8	36	4	low	-40~125	96	12.2	54	14	SO14	SOT108-1	NAND gates
74HC03PW	Production	HC(T)	NAND gates	Quad 2-input NANDgate; open-drain	2.0 - 6.0	CMOS	5.2	8	36	4	low	-40~125	133	5.2	58.6	14	TSSOP14	SOT402-1	NAND gates
74HCT03D	Production	HC(T)	NAND gates	Quad 2-input NANDgate; open-drain; TTL enabled	4.5 - 5.5	TTL	± 4	10	36	4	low	-40~125	98	13.4	56	14	SO14	SOT108-1	NAND gates
74HCT03PW	Production	HC(T)	NAND gates	Quad 2-input NANDgate; open-drain; TTL enabled	4.5 - 5.5	TTL	± 4	10	36	4	low	-40~125	133	5.2	58.6	14	TSSOP14	SOT402-1	NAND gates
74HC08BQ	Production	HC(T)	AND gates	Quad 2-input AND gate	2.0 - 6.0	CMOS	± 5.2	7	36	4	low	-40~125	107	21.5	75	14	DHVQFN14	SOT762-1	AND gates
74HC08D	Production	HC(T)	AND gates	Quad 2-input AND gate	2.0 - 6.0	CMOS	± 5.2	7	36	4	low	-40~125	109	20.8	67	14	SO14	SOT108-1	AND gates
74HC08PW	Production	HC(T)	AND gates	Quad 2-input AND gate	2.0 - 6.0	CMOS	± 5.2	7	36	4	low	-40~125	142	8	68	14	TSSOP14	SOT402-1	AND gates
74HCT08BQ	Production	HC(T)	AND gates	Quad 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 4	11	36	4	low	-40~125	107	21.5	75	14	DHVQFN14	SOT762-1	AND gates
74HCT08D	Production	HC(T)	AND gates	Quad 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 4	11	36	4	low	-40~125	109	20.8	67	14	SO14	SOT108-1	AND gates
74HCT08PW	Production	HC(T)	AND gates	Quad 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 4	11	36	4	low	-40~125	142	8	68	14	TSSOP14	SOT402-1	AND gates
74HC10D	Production	HC(T)	NAND gates	Triple 3-input NANDgate	2.0 - 6.0	CMOS	± 5.2	9	36	3	low	-40~125	108	20.4	67	14	SO14	SOT108-1	NAND gates
74HC10PW	Production	HC(T)	NAND gates	Triple 3-input NANDgate	2.0 - 6.0	CMOS	± 5.2	9	36	3	low	-40~125	141	7.9	68	14	TSSOP14	SOT402-1	NAND gates
74HCT10D	Production	HC(T)	NAND gates	Triple 3-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 4	11	36	3	low	-40~125	108	20.4	67	14	SO14	SOT108-1	NAND gates
74HCT10PW	Production	HC(T)	NAND gates	Triple 3-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 4	11	36	3	low	-40~125	141	7.9	68	14	TSSOP14	SOT402-1	NAND gates
74HC11D	Production	HC(T)	AND gates	Triple 3-input ANDgate	2.0 - 6.0	CMOS	± 5.2	10	36	3	low	-40~125	96	11.9	54	14	SO14	SOT108-1	AND gates
74HC11PW	Production	HC(T)	AND gates	Triple 3-input ANDgate	2.0 - 6.0	CMOS	± 5.2	10	36	3	low	-40~125	131	4.6	56.7	14	TSSOP14	SOT402-1	AND gates
74HCT11D	Production	HC(T)	AND gates	Triple 3-input ANDgate	4.5 - 5.5	TTL	± 4	11	36	3	low	-40~125	94	10.8	52	14	SO14	SOT108-1	AND gates
74HCT11PW	Production	HC(T)	AND gates	Triple 3-input ANDgate	4.5 - 5.5	TTL	± 4	11	36	3	low	-40~125	131	4.6	56.7	14	TSSOP14	SOT402-1	AND gates
74HC20D	Production	HC(T)	NAND gates	Dual 4-input NANDgate	2.0 - 6.0	CMOS	± 5.2	8	36	2	low	-40~125	94	10.9	52	14	SO14	SOT108-1	NAND gates
74HC20PW	Production	HC(T)	NAND gates	Dual 4-input NANDgate	2.0 - 6.0	CMOS	± 5.2	8	36	2	low	-40~125	132	4.7	56.9	14	TSSOP14	SOT402-1	NAND gates
74HCT20D	Production	HC(T)	NAND gates	Dual 4-input NANDgate; TTL enabled	4.5 - 5.5	TTL	± 4	13	36	2	low	-40~125	76	1	34	14	SO14	SOT108-1	NAND gates
74HC27BQ	Production	HC(T)	NOR gates	Triple 3-input NORgate	2.0 - 6.0	CMOS	± 5.2	8	36	3	low	-40~125	107	21.7	75	14	DHVQFN14	SOT762-1	NOR gates
74HC27D	Production	HC(T)	NOR gates	Triple 3-input NORgate	2.0 - 6.0	CMOS	± 5.2	8	36	3	low	-40~125	109	20.9	68	14	SO14	SOT108-1	NOR gates
74HC27PW	Production	HC(T)	NOR gates	Triple 3-input NORgate	2.0 - 6.0	CMOS	± 5.2	8	36	3	low	-40~125	142	8.1	68	14	TSSOP14	SOT402-1	NOR gates
74HCT27BQ	Production	HC(T)	NOR gates	Triple 3-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 4	10	36	3	low	-40~125	107	21.7	75	14	DHVQFN14	SOT762-1	NOR gates
74HCT27D	Production	HC(T)	NOR gates	Triple 3-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 4	10	36	3	low	-40~125	109	20.9	68	14	SO14	SOT108-1	NOR gates
74HCT27PW	Production	HC(T)	NOR gates	Triple 3-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 4	10	36	3	low	-40~125	142	8.1	68	14	TSSOP14	SOT402-1	NOR gates
74HC30D	Production	HC(T)	NAND gates	8-input NAND gate	2.0 - 6.0	CMOS	± 5.2	12	36	1	low	-40~125	88	7	46	14	SO14	SOT108-1	NAND gates
74HC30PW	Production	HC(T)	NAND gates	8-input NAND gate	2.0 - 6.0	CMOS	± 5.2	12	36	1	low	-40~125	126	2.8	50.4	14	TSSOP14	SOT402-1	NAND gates
74HCT30D	Production	HC(T)	NAND gates	8-input NAND gate;TTL enabled	4.5 - 5.5	TTL	± 4	12	36	1	low	-40~125	85	5.1	43	14	SO14	SOT108-1	NAND gates
74HCT30PW	Production	HC(T)	NAND gates	8-input NAND gate;TTL enabled	4.5 - 5.5	TTL	± 4	12	36	1	low	-40~125	126	2.8	50.4	14	TSSOP14	SOT402-1	NAND gates
74HC32BQ	Production	HC(T)	OR gates	Quad 2-input OR gate	2.0 - 6.0	CMOS	± 5.2	6	36	4	low	-40~125	107	21.8	75	14	DHVQFN14	SOT762-1	OR gates
74HC32D	Production	HC(T)	OR gates	Quad 2-input OR gate	2.0 - 6.0	CMOS	± 5.2	6	36	4	low	-40~125	109	21	68	14	SO14	SOT108-1	OR gates
74HC32PW	Production	HC(T)	OR gates	Quad 2-input OR gate	2.0 - 6.0	CMOS	± 5.2	6	36	4	low	-40~125	142	8.1	68	14	TSSOP14	SOT402-1	OR gates
74HCT32BQ	Production	HC(T)	OR gates	Quad 2-input OR gate	4.5 - 5.5	TTL	± 4	9	36	4	low	-40~125	107	21.8	75	14	DHVQFN14	SOT762-1	OR gates
74HCT32D	Production	HC(T)	OR gates	Quad 2-input OR gate;TTL enabled	4.5 - 5.5	TTL	± 4	9	36	4	low	-40~125	109	21	68	14	SO14	SOT108-1	OR gates
74HCT32PW	Production	HC(T)	OR gates	Quad 2-input OR gate;TTL enabled	4.5 - 5.5	TTL	± 4	9	36	4	low	-40~125	142	8.1	68	14	TSSOP14	SOT402-1	OR gates
74HC86D	Production	HC(T)	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate	2.0 - 6.0	CMOS	± 5.2	11	36	4	low	-40~125	109	20.5	67	14	SO14	SOT108-1	EXCLUSIVE-OR gates
74HC86PW	Production	HC(T)	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate	2.0 - 6.0	CMOS	± 5.2	11	36	4	low	-40~125	141	7.9	68	14	TSSOP14	SOT402-1	EXCLUSIVE-OR gates
74HCT86D	Production	HC(T)	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate; TTL enabled	4.5 - 5.5	TTL	± 4	14	36	4	low	-40~125	109	20.5	67	14	SO14	SOT108-1	EXCLUSIVE-OR gates
74HCT86PW	Production	HC(T)	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate; TTL enabled	4.5 - 5.5	TTL	± 4	14	36	4	low	-40~125	141	7.9	68	14	TSSOP14	SOT402-1	EXCLUSIVE-OR gates
74HC132BQ	Production	HC(T)	NAND gates	Quad 2-input NANDgate Schmitt-trigger	2.0 - 6.0	CMOS	± 5.2	11	36	4	low	-40~125	107	21	75	14	DHVQFN14	SOT762-1	NAND gates
74HC132D	Production	HC(T)	NAND gates	Quad 2-input NANDgate Schmitt-trigger	2.0 - 6.0	CMOS	± 5.2	11	36	4	low	-40~125	109	20.6	67	14	SO14	SOT108-1	Schmitt-triggers
74HC132PW	Production	HC(T)	NAND gates	Quad 2-input NANDgate Schmitt-trigger	2.0 - 6.0	CMOS	± 5.2	11	36	4	low	-40~125	141	8	68	14	TSSOP14	SOT402-1	Schmitt-triggers
74HCT132D	Production	HC(T)	NAND gates	Quad 2-input NANDgate Schmitt-trigger; TTL enabled	4.5 - 5.5	TTL	± 4	17	36	4	low	-40~125	109	20.6	67	14	SO14	SOT108-1	Schmitt-triggers
74HCT132PW	Production	HC(T)	NAND gates	Quad 2-input NANDgate Schmitt-trigger; TTL enabled	4.5 - 5.5	TTL	± 4	17	36	4	low	-40~125	141	7.9	68	14	TSSOP14	SOT402-1	Schmitt-triggers
74HC4002D	Production	HC(T)	NOR gates	Dual 4-input NOR gate	2.0 - 6.0	CMOS	± 5.2	9	36	2	low	-40~125	90	8.4	48	14	SO14	SOT108-1	NOR gates
74HC4002PW	Production	HC(T)	NOR gates	Dual 4-input NOR gate	2.0 - 6.0	CMOS	± 5.2	9	36	2	low	-40~125	129	4	54.5	14	TSSOP14	SOT402-1	NOR gates
74HCT4002D	Production	HC(T)	NOR gates	Dual 4-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 4	11	36	2	low	-40~125	85	4.8	42	14	SO14	SOT108-1	NOR gates
74HC4075D	Production	HC(T)	OR gates	Triple 3-input ORgate	2.0 - 6.0	CMOS	± 5.2	8	36	3	low	-40~125	65	1	22	14	SO14	SOT108-1	OR gates
74HCT4075D	Production	HC(T)	OR gates	Triple 3-input ORgate; TTL enabled	4.5 - 5.5	TTL	± 4	10	36	3	low	-40~125	65	1	22	14	SO14	SOT108-1	OR gates
74LV1T00GV	Production	LV	NAND gate	2-input single supplytranslating NAND gate	1.6 - 5.5	CMOS	± 8	14.4		1	low	-40~125				5	TSOP5	SOT753	Levelshifters/translators
74LV1T00GW	Production	LV	NAND gate	2-input single supplytranslating NAND gate	1.6 - 5.5	CMOS	± 8	14.4		1	low	-40~125	316	85.8	186	5	TSSOP5	SOT353-1	Levelshifters/translators
74LV1T00GX	Production	LV	NAND gate	2-input single supplytranslating NAND gate	1.6 - 5.5	CMOS	± 8	14.4		1	low	-40~125	340	105	206	5	X2SON5	SOT1226	Levelshifters/translators
74LV1T02GV	Production	LV	NOR gate	2-input single supplytranslating NOR gate	1.6 - 5.5	CMOS	± 8	14.3		1	low	-40~125				5	TSOP5	SOT753	Levelshifters/translators
74LV1T02GW	Production	LV	NOR gate	2-input single supplytranslating NOR gate	1.6 - 5.5	CMOS	± 8	14.3		1	low	-40~125	316	85.8	186	5	TSSOP5	SOT353-1	Levelshifters/translators
74LV1T02GX	Production	LV	NOR gate	2-input single supplytranslating NOR gate	1.6 - 5.5	CMOS	± 8	14.3		1	low	-40~125	340	105	206	5	X2SON5	SOT1226	Levelshifters/translators
74LV1T08GV	Production	LV	AND gate	2-input single supplytranslating AND gate	1.6 - 5.5	CMOS	± 8	13.4		1	low	-40~125				5	TSOP5	SOT753	Levelshifters/translators
74LV1T08GW	Production	LV	AND gate	2-input single supplytranslating AND gate	1.6 - 5.5	CMOS	± 8	13.4		1	low	-40~125	316	85.8	186	5	TSSOP5	SOT353-1	Levelshifters/translators
74LV1T08GX	Production	LV	AND gate	2-input single supplytranslating AND gate	1.6 - 5.5	CMOS	± 8	13.4		1	low	-40~125	340	105	206	5	X2SON5	SOT1226	Levelshifters/translators
74LV1T32GV	Production	LV	OR gate	2-input single supplytranslating OR gate	1.6 - 5.5	CMOS	± 8	13.3		1	low	-40~125				5	TSOP5	SOT753	Levelshifters/translators
74LV1T32GW	Production	LV	OR gate	2-input single supplytranslating OR gate	1.6 - 5.5	CMOS	± 8	13.3		1	low	-40~125	316	85.8	186	5	TSSOP5	SOT353-1	Levelshifters/translators
74LV1T32GX	Production	LV	OR gate	2-input single supplytranslating OR gate	1.6 - 5.5	CMOS	± 8	13.3		1	low	-40~125	340	105	206	5	X2SON5	SOT1226	Levelshifters/translators
74LV1T86GV	Production	LV	EXCLUSIVE-OR gate	2-input single supplytranslating X-OR gate	1.6 - 5.5	CMOS	± 8	15.8		1	low	-40~125				5	TSOP5	SOT753	Levelshifters/translators
74LV1T86GW	Production	LV	EXCLUSIVE-OR gate	2-input single supplytranslating X-OR gate	1.6 - 5.5	CMOS	± 8	15.8		1	low	-40~125	316	85.8	186	5	TSSOP5	SOT353-1	Levelshifters/translators
74LV1T86GX	Production	LV	EXCLUSIVE-OR gate	2-input single supplytranslating X-OR gate	1.6 - 5.5	CMOS	± 8	15.8		1	low	-40~125	340	105	206	5	X2SON5	SOT1226	Levelshifters/translators
74LV1T87GV	Production	LV	EXCLUSIVE-NOR gate	2-input single supplytranslating X-NOR gate	1.6 - 5.5	CMOS	± 8	15.8		1	low	-40~125				5	TSOP5	SOT753	Levelshifters/translators
74LV1T87GW	Production	LV	EXCLUSIVE-NOR gate	2-input single supplytranslating X-NOR gate	1.6 - 5.5	CMOS	± 8	15.8		1	low	-40~125	316	85.8	186	5	TSSOP5	SOT353-1	Levelshifters/translators
74LV1T87GX	Production	LV	EXCLUSIVE-NOR gate	2-input single supplytranslating X-NOR gate	1.6 - 5.5	CMOS	± 8	15.8		1	low	-40~125	340	105	206	5	X2SON5	SOT1226	Levelshifters/translators
74LV00BQ	Production	LV	NAND gates	Quad 2-input NANDgate	1.0 - 5.5	TTL	± 12	7	30	4	low	-40~125	95	11.7	62	14	DHVQFN14	SOT762-1	NAND gates
74LV00D	Production	LV	NAND gates	Quad 2-input NANDgate	1.0 - 5.5	TTL	± 12	7	30	4	low	-40~125	93	10.3	51	14	SO14	SOT108-1	NAND gates
74LV00PW	Production	LV	NAND gates	Quad 2-input NANDgate	1.0 - 5.5	TTL	± 12	7	30	4	low	-40~125	131	4.5	56.3	14	TSSOP14	SOT402-1	NAND gates
74LV00APW	Production	LV-A	NAND gates	Quad 2-input NANDgate	2.0 - 5.5	CMOS	± 12	4.3	45	4	low	-40~125	140	7.5	66	14	TSSOP14	SOT402-1	NAND gates
74LV02BQ	Production	LV	NOR	Quad 2-input NOR gate	1.0 - 5.5	TTL	± 12	6	30	4	low	-40~125	92	9.3	59	14	DHVQFN14	SOT762-1	NOR gates
74LV02D	Production	LV	NOR	Quad 2-input NOR gate	1.0 - 5.5	TTL	± 12	6	30	4	low	-40~125	90	8	47	14	SO14	SOT108-1	NOR gates
74LV02PW	Production	LV	NOR	Quad 2-input NOR gate	1.0 - 5.5	TTL	± 12	6	30	4	low	-40~125	128	3.7	53.4	14	TSSOP14	SOT402-1	NOR gates
74LV02APW	Production	LV-A	NOR	Quad 2-input NOR gate	2.0 - 5.5	CMOS	± 12	4.3	45	4	low	-40~125	140	7.5	66	14	TSSOP14	SOT402-1	NOR gates
74LV03D	Production	LV	NAND gates	Quad 2-input NANDgate; open-drain	1.0 - 5.5	TTL	± 12	8	30	4	low	-40~125	96	12.2	54	14	SO14	SOT108-1	NAND gates
74LV08D	Production	LV	AND gates	Quad 2-input AND gate	1.0 - 5.5	TTL	± 12	7	30	4	low	-40~125	87	6.6	45	14	SO14	SOT108-1	AND gates
74LV08PW	Production	LV	AND gates	Quad 2-input AND gate	1.0 - 5.5	TTL	± 12	7	30	4	low	-40~125	127	3.1	51.4	14	TSSOP14	SOT402-1	AND gates
74LV08APW	Production	LV-A	AND gates	Quad 2-input AND gate	2.0 - 5.5	CMOS	± 12	4.3	45	4	low	-40~125	140	7.5	66	14	TSSOP14	SOT402-1	AND gates
74LV32APW	Production	LV-A	OR gates	Quad 2-input OR gate	2.0 - 5.5	CMOS	± 12	4.2	45	4	low	-40~125	140	7.5	66	14	TSSOP14	SOT402-1	OR gates
74LV132BQ	Production	LV	NAND gates	Quad 2-input NANDgate Schmitt-trigger	1.0 - 5.5	TTL	± 12	10	30	4	low	-40~125	94	11.2	61	14	DHVQFN14	SOT762-1	Schmitt-triggers
74LV132D	Production	LV	NAND gates	Quad 2-input NANDgate Schmitt-trigger	1.0 - 5.5	TTL	± 12	10	30	4	low	-40~125	92	9.8	50	14	SO14	SOT108-1	Schmitt-triggers
74LV132PW	Production	LV	NAND gates	Quad 2-input NANDgate Schmitt-trigger	1.0 - 5.5	TTL	± 12	10	30	4	low	-40~125	130	4.3	55.6	14	TSSOP14	SOT402-1	Schmitt-triggers
74LV7032APW	Production	LV-A	OR gates	Quad 2-input OR gateSchmitt trigger	2.0 - 5.5	CMOS	± 12	4.3	45	4	low	-40~125	140	7.5	66	14	TSSOP14	SOT402-1	Schmitt-triggers
74LVC1G00GM	Production	LVC	NAND gate	Single 2-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	175	1	low	-40~125	313	7.8	158	6	XSON6	SOT886	NAND gates
74LVC1G00GN	Production	LVC	NAND gate	Single 2-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	175	1	low	-40~125	338	23.5	210	6	XSON6	SOT1115	NAND gates
74LVC1G00GS	Production	LVC	NAND gate	Single 2-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	175	1	low	-40~125	325	29.9	218	6	XSON6	SOT1202	NAND gates
74LVC1G00GV	Production	LVC	NAND gate	Single 2-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	175	1	low	-40~125	270	63.3	169	5	TSOP5	SOT753	NAND gates
74LVC1G00GW	Production	LVC	NAND gate	Single 2-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	175	1	low	-40~125	311	80.9	181	5	TSSOP5	SOT353-1	NAND gates
74LVC1G00GX	Production	LVC	NAND gate	Single 2-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	175	1	low	-40~125	327	94.5	195	5	X2SON5	SOT1226	NAND gates
74LVC1G02GM	Production	LVC	NOR gate	Single 2-input NORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.1	150	1	low	-40~125	313	7.8	158	6	XSON6	SOT886	NOR gates
74LVC1G02GN	Production	LVC	NOR gate	Single 2-input NORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.1	150	1	low	-40~125	338	23.5	210	6	XSON6	SOT1115	NOR gates
74LVC1G02GS	Production	LVC	NOR gate	Single 2-input NORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.1	150	1	low	-40~125	325	29.9	218	6	XSON6	SOT1202	NOR gates
74LVC1G02GV	Production	LVC	NOR gate	Single 2-input NORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.1	150	1	low	-40~125	270	63.3	169	5	TSOP5	SOT753	NOR gates
74LVC1G02GW	Production	LVC	NOR gate	Single 2-input NORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.1	150	1	low	-40~125	311	80.9	181	5	TSSOP5	SOT353-1	NOR gates
74LVC1G02GX	Production	LVC	NOR gate	Single 2-input NORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.1	150	1	low	-40~125	327	94.5	195	5	X2SON5	SOT1226	NOR gates
74LVC1G08GM	Production	LVC	AND gate	Single 2-input ANDgate	1.65 - 5.5	CMOS / LVTTL	± 24	2.1	150	1	low	-40~125	313	7.8	158	6	XSON6	SOT886	AND gates
74LVC1G08GN	Production	LVC	AND gate	Single 2-input ANDgate	1.65 - 5.5	CMOS / LVTTL	± 24	2.1	150	1	low	-40~125	338	23.5	210	6	XSON6	SOT1115	AND gates
74LVC1G08GS	Production	LVC	AND gate	Single 2-input ANDgate	1.65 - 5.5	CMOS / LVTTL	± 24	2.1	150	1	low	-40~125	325	29.9	218	6	XSON6	SOT1202	AND gates
74LVC1G08GV	Production	LVC	AND gate	Single 2-input ANDgate	1.65 - 5.5	CMOS / LVTTL	± 24	2.1	150	1	low	-40~125	270	63.3	169	5	TSOP5	SOT753	AND gates
74LVC1G08GW	Production	LVC	AND gate	Single 2-input ANDgate	1.65 - 5.5	CMOS / LVTTL	± 24	2.1	150	1	low	-40~125	311	80.9	181	5	TSSOP5	SOT353-1	AND gates
74LVC1G08GX	Production	LVC	AND gate	Single 2-input ANDgate	1.65 - 5.5	CMOS / LVTTL	± 24	2.1	150	1	low	-40~125	327	94.5	195	5	X2SON5	SOT1226	AND gates
74LVC1G10GM	Production	LVC	NAND gate	Single 3-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	175	1	low	-40~125	317	8	161	6	XSON6	SOT886	NAND gates
74LVC1G10GN	Production	LVC	NAND gate	Single 3-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	175	1	low	-40~125	351	26	218	6	XSON6	SOT1115	NAND gates
74LVC1G10GS	Production	LVC	NAND gate	Single 3-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	175	1	low	-40~125	336	33	226	6	XSON6	SOT1202	NAND gates
74LVC1G10GV	Production	LVC	NAND gate	Single 3-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	175	1	low	-40~125	261	63	172	6	SC-74; TSOP6	SOT457	NAND gates
74LVC1G10GW	Production	LVC	NAND gate	Single 3-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	175	1	low	-40~125	284	56.2	172	6	TSSOP6	SOT363	NAND gates
74LVC1G11GM	Production	LVC	AND gate	Single 3-input ANDgate	1.65 - 5.5	CMOS / LVTTL	± 32	2.6	175	1	low	-40~125	318	8.1	162	6	XSON6	SOT886	AND gates
74LVC1G11GN	Production	LVC	AND gate	Single 3-input ANDgate	1.65 - 5.5	CMOS / LVTTL	± 32	2.6	175	1	low	-40~125	354	26.4	219	6	XSON6	SOT1115	AND gates
74LVC1G11GS	Production	LVC	AND gate	Single 3-input ANDgate	1.65 - 5.5	CMOS / LVTTL	± 32	2.6	175	1	low	-40~125	337	33.5	228	6	XSON6	SOT1202	AND gates
74LVC1G11GV	Production	LVC	AND gate	Single 3-input ANDgate	1.65 - 5.5	CMOS / LVTTL	± 32	2.6	175	1	low	-40~125	261	63	172	6	SC-74; TSOP6	SOT457	AND gates
74LVC1G11GW	Production	LVC	AND gate	Single 3-input ANDgate	1.65 - 5.5	CMOS / LVTTL	± 32	2.6	175	1	low	-40~125	284	56.7	172	6	TSSOP6	SOT363	AND gates
74LVC1G11GX	Production	LVC	AND gate	Single 3-input ANDgate	1.65 - 5.5	CMOS / LVTTL	± 32	2.6	175	1	low	-40~125				6	X2SON6	SOT1255	AND gates
74LVC1G27GM	Production	LVC	NOR gate	Single 3-input NORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	150	1	low	-40~125	317	8	161	6	XSON6	SOT886	NOR gates
74LVC1G27GN	Production	LVC	NOR gate	Single 3-input NORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	150	1	low	-40~125	351	26	218	6	XSON6	SOT1115	NOR gates
74LVC1G27GS	Production	LVC	NOR gate	Single 3-input NORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	150	1	low	-40~125	336	33	226	6	XSON6	SOT1202	NOR gates
74LVC1G27GV	Production	LVC	NOR gate	Single 3-input NORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	150	1	low	-40~125	261	63	172	6	SC-74; TSOP6	SOT457	NOR gates
74LVC1G27GW	Production	LVC	NOR gate	Single 3-input NORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	150	1	low	-40~125	284	56.2	172	6	TSSOP6	SOT363	NOR gates
74LVC1G32GM	Production	LVC	OR gate	Single 2-input ORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.1	150	1	low	-40~125	313	7.8	158	6	XSON6	SOT886	OR gates
74LVC1G32GN	Production	LVC	OR gate	Single 2-input ORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.1	150	1	low	-40~125	338	23.5	210	6	XSON6	SOT1115	OR gates
74LVC1G32GS	Production	LVC	OR gate	Single 2-input ORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.1	150	1	low	-40~125	325	29.9	218	6	XSON6	SOT1202	OR gates
74LVC1G32GV	Production	LVC	OR gate	Single 2-input ORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.1	150	1	low	-40~125	270	63.3	169	5	TSOP5	SOT753	OR gates
74LVC1G32GW	Production	LVC	OR gate	Single 2-input ORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.1	150	1	low	-40~125	311	80.9	181	5	TSSOP5	SOT353-1	OR gates
74LVC1G32GX	Production	LVC	OR gate	Single 2-input ORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.1	150	1	low	-40~125	327	94.5	195	5	X2SON5	SOT1226	OR gates
74LVC1G38GM	Production	LVC	NAND gate	Single 2-input NANDgate; open-drain	1.65 - 5.5	CMOS/LVTTL	32	2.3	175	1	low	-40~125	313	7.8	158	6	XSON6	SOT886	NAND gates
74LVC1G38GN	Production	LVC	NAND gate	Single 2-input NANDgate; open-drain	1.65 - 5.5	CMOS/LVTTL	32	2.3	175	1	low	-40~125	338	23.5	210	6	XSON6	SOT1115	NAND gates
74LVC1G38GS	Production	LVC	NAND gate	Single 2-input NANDgate; open-drain	1.65 - 5.5	CMOS/LVTTL	32	2.3	175	1	low	-40~125	325	29.9	218	6	XSON6	SOT1202	NAND gates
74LVC1G38GV	Production	LVC	NAND gate	Single 2-input NANDgate; open-drain	1.65 - 5.5	CMOS/LVTTL	32	2.3	175	1	low	-40~125	270	63.3	169	5	TSOP5	SOT753	NAND gates
74LVC1G38GW	Production	LVC	NAND gate	Single 2-input NANDgate; open-drain	1.65 - 5.5	CMOS/LVTTL	32	2.3	175	1	low	-40~125	311	80.9	181	5	TSSOP5	SOT353-1	NAND gates
74LVC1G38GX	Production	LVC	NAND gate	Single 2-input NANDgate; open-drain	1.65 - 5.5	CMOS/LVTTL	32	2.3	175	1	low	-40~125	327	94.5	195	5	X2SON5	SOT1226	NAND gates
74LVC1G57GM	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	308	7.5	155	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74LVC1G57GN	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	325	21	201	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74LVC1G57GS	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	313	26.6	209	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74LVC1G57GV	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	250	54.7	163	6	SC-74; TSOP6	SOT457	Configurable gates;Schmitt-trigger
74LVC1G57GW	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	277	50.1	165	6	TSSOP6	SOT363	Configurable gates;Schmitt-trigger
74LVC1G58GM	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	308	7.5	155	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74LVC1G58GN	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	325	21	201	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74LVC1G58GS	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	313	26.6	209	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74LVC1G58GV	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	250	54.7	163	6	SC-74; TSOP6	SOT457	Configurable gates;Schmitt-trigger
74LVC1G58GW	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	277	50.1	165	6	TSSOP6	SOT363	Configurable gates;Schmitt-trigger
74LVC1G86GM	Production	LVC	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.4	150	1	low	-40~125	313	7.8	158	6	XSON6	SOT886	EXCLUSIVE-ORgates
74LVC1G86GN	Production	LVC	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.4	150	1	low	-40~125	338	23.5	210	6	XSON6	SOT1115	EXCLUSIVE-OR gates
74LVC1G86GS	Production	LVC	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.4	150	1	low	-40~125	325	29.9	218	6	XSON6	SOT1202	EXCLUSIVE-OR gates
74LVC1G86GV	Production	LVC	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.4	150	1	low	-40~125	270	63.3	169	5	TSOP5	SOT753	EXCLUSIVE-OR gates
74LVC1G86GW	Production	LVC	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.4	150	1	low	-40~125	311	80.9	181	5	TSSOP5	SOT353-1	EXCLUSIVE-OR gates
74LVC1G86GX	Production	LVC	EXCLUSIVE-OR gate	Single 2-inputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.4	150	1	low	-40~125	327	94.5	195	5	X2SON5	SOT1226	EXCLUSIVE-OR gates
74LVC1G97GM	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	308	7.5	155	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74LVC1G97GN	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	325	21	201	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74LVC1G97GS	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	313	26.6	209	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74LVC1G97GV	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	237	43.9	150	6	SC-74; TSOP6	SOT457	Configurable gates;Schmitt-trigger
74LVC1G97GW	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	277	50.1	165	6	TSSOP6	SOT363	Configurable gates;Schmitt-trigger
74LVC1G97GX	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125				6	X2SON6	SOT1255	Configurable gates;Schmitt-trigger
74LVC1G98GM	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	308	7.5	155	6	XSON6	SOT886	Configurable gates;Schmitt-trigger
74LVC1G98GN	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	325	21	201	6	XSON6	SOT1115	Configurable gates;Schmitt-trigger
74LVC1G98GS	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	313	26.6	209	6	XSON6	SOT1202	Configurable gates;Schmitt-trigger
74LVC1G98GV	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	237	43.9	150	6	SC-74; TSOP6	SOT457	Configurable gates;Schmitt-trigger
74LVC1G98GW	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	6.3	150	1	low	-40~125	277	50.1	165	6	TSSOP6	SOT363	Configurable gates;Schmitt-trigger
74LVC1G99DP	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	8.4	150	1	low	-40~125	221	21.6	107	8	TSSOP8	SOT505-2	Configurable gates;Schmitt-trigger
74LVC1G99GN	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	8.4	150	1	low	-40~125	249	12.4	156	8	XSON8	SOT1116	Configurable gates;Schmitt-trigger
74LVC1G99GS	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	8.4	150	1	low	-40~125	287	12.6	153	8	XSON8	SOT1203	Configurable gates;Schmitt-trigger
74LVC1G99GT	Production	LVC	Configurable gate	Configurable gate;Schmitt trigger	1.65 - 5.5	TTL	± 32	8.4	150	1	low	-40~125	342	7	168	8	XSON8	SOT833-1	Configurable gates;Schmitt-trigger
74LVC1G332GM	Production	LVC	OR gate	Single 3-input ORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	150	1	low	-40~125	317	8	161	6	XSON6	SOT886	OR gates
74LVC1G332GN	Production	LVC	OR gate	Single 3-input ORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	150	1	low	-40~125	351	26	218	6	XSON6	SOT1115	OR gates
74LVC1G332GS	Production	LVC	OR gate	Single 3-input ORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	150	1	low	-40~125	336	33	226	6	XSON6	SOT1202	OR gates
74LVC1G332GV	Production	LVC	OR gate	Single 3-input ORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	150	1	low	-40~125	261	63	172	6	SC-74; TSOP6	SOT457	OR gates
74LVC1G332GW	Production	LVC	OR gate	Single 3-input ORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	150	1	low	-40~125	284	56.2	172	6	TSSOP6	SOT363	OR gates
74LVC1G332GX	Production	LVC	OR gate	Single 3-input ORgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.6	150	1	low	-40~125				6	X2SON6	SOT1255	OR gates
74LVC1G386GV	Production	LVC	EXCLUSIVE-OR gate	Single 3-InputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	4.5	150	1	low	-40~125	261	63.4	172	6	SC-74; TSOP6	SOT457	EXCLUSIVE-OR gates
74LVC1G386GW	Production	LVC	EXCLUSIVE-OR gate	Single 3-InputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	4.5	150	1	low	-40~125	284	56.7	172	6	TSSOP6	SOT363	EXCLUSIVE-OR gates
74LVC1GX04GV	Production	LVC	Combination gate	Crystal driver	1.65 - 5.5	CMOS / LVTTL	± 24	2.8	150	1	low	-40~125	232	39.4	145	6	SC-74; TSOP6	SOT457	Combination
74LVC1GX04GW	Production	LVC	Combination gate	Crystal driver	1.65 - 5.5	CMOS / LVTTL	± 24	2.8	150	1	low	-40~125	264	38.4	153	6	TSSOP6	SOT363	Combination
74LVC2G00DC	Production	LVC	NAND gates	Dual 2-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	175	2	low	-40~125	200	32.4	110	8	VSSOP8	SOT765-1	NAND gates
74LVC2G00DP	Production	LVC	NAND gates	Dual 2-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	175	2	low	-40~125	210	18.8	104	8	TSSOP8	SOT505-2	NAND gates
74LVC2G00GN	Production	LVC	NAND gates	Dual 2-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	175	2	low	-40~125	231	9.5	142	8	XSON8	SOT1116	NAND gates
74LVC2G00GS	Production	LVC	NAND gates	Dual 2-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	175	2	low	-40~125	269	9.7	141	8	XSON8	SOT1203	NAND gates
74LVC2G00GT	Production	LVC	NAND gates	Dual 2-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	175	2	low	-40~125	317	5.6	150	8	XSON8	SOT833-1	NAND gates
74LVC2G00GX	Production	LVC	NAND gates	Dual 2-input NANDgate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	175	2	low	-40~125				8	X2SON8	SOT1233	NAND gates
74LVC2G02DC	Production	LVC	NOR gates	Dual 2-input NOR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.4	150	2	low	-40~125	200	32.4	110	8	VSSOP8	SOT765-1	NOR gates
74LVC2G02DP	Production	LVC	NOR gates	Dual 2-input NOR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.4	150	2	low	-40~125	210	18.8	104	8	TSSOP8	SOT505-2	NOR gates
74LVC2G02GN	Production	LVC	NOR gates	Dual 2-input NOR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.4	150	2	low	-40~125	231	9.5	142	8	XSON8	SOT1116	NOR gates
74LVC2G02GS	Production	LVC	NOR gates	Dual 2-input NOR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.4	150	2	low	-40~125	269	9.7	141	8	XSON8	SOT1203	NOR gates
74LVC2G02GT	Production	LVC	NOR gates	Dual 2-input NOR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.4	150	2	low	-40~125	317	5.6	150	8	XSON8	SOT833-1	NOR gates
74LVC2G08DC	Production	LVC	AND gates	Dual 2-input AND gate	1.65 - 5.5	CMOS / LVTTL	± 24	2.1	150	2	low	-40~125	200	32.4	110	8	VSSOP8	SOT765-1	AND gates
74LVC2G08DP	Production	LVC	AND gates	Dual 2-input AND gate	1.65 - 5.5	CMOS / LVTTL	± 24	2.1	150	2	low	-40~125	210	18.8	104	8	TSSOP8	SOT505-2	AND gates
74LVC2G08GN	Production	LVC	AND gates	Dual 2-input AND gate	1.65 - 5.5	CMOS / LVTTL	± 24	2.1	150	2	low	-40~125	231	9.5	142	8	XSON8	SOT1116	AND gates
74LVC2G08GS	Production	LVC	AND gates	Dual 2-input AND gate	1.65 - 5.5	CMOS / LVTTL	± 24	2.1	150	2	low	-40~125	269	9.7	141	8	XSON8	SOT1203	AND gates
74LVC2G08GT	Production	LVC	AND gates	Dual 2-input AND gate	1.65 - 5.5	CMOS / LVTTL	± 24	2.1	150	2	low	-40~125	317	5.6	150	8	XSON8	SOT833-1	AND gates
74LVC2G08GX	Production	LVC	AND gates	Dual 2-input AND gate	1.65 - 5.5	CMOS / LVTTL	± 24	2.1	150	2	low	-40~125				8	X2SON8	SOT1233	AND gates
74LVC2G32DC	Production	LVC	OR gates	Dual 2-input OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	150	2	low	-40~125	200	32.4	110	8	VSSOP8	SOT765-1	OR gates
74LVC2G32DP	Production	LVC	OR gates	Dual 2-input OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	150	2	low	-40~125	210	18.8	104	8	TSSOP8	SOT505-2	OR gates
74LVC2G32GN	Production	LVC	OR gates	Dual 2-input OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	150	2	low	-40~125	231	9.5	142	8	XSON8	SOT1116	OR gates
74LVC2G32GS	Production	LVC	OR gates	Dual 2-input OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	150	2	low	-40~125	269	9.7	141	8	XSON8	SOT1203	OR gates
74LVC2G32GT	Production	LVC	OR gates	Dual 2-input OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	150	2	low	-40~125	317	5.6	150	8	XSON8	SOT833-1	OR gates
74LVC2G32GX	Production	LVC	OR gates	Dual 2-input OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.2	150	2	low	-40~125				8	X2SON8	SOT1233	OR gates
74LVC2G38DC	Production	LVC	NAND gates	Dual 2-input NANDgate; open-drain	1.65 - 5.5	CMOS/LVTTL	32	2.1	175	2	low	-40~125	200	32.4	110	8	VSSOP8	SOT765-1	NAND gates
74LVC2G38DP	Production	LVC	NAND gates	Dual 2-input NANDgate; open-drain	1.65 - 5.5	CMOS/LVTTL	32	2.1	175	2	low	-40~125	210	18.8	104	8	TSSOP8	SOT505-2	NAND gates
74LVC2G38GN	Production	LVC	NAND gates	Dual 2-input NANDgate; open-drain	1.65 - 5.5	CMOS/LVTTL	32	2.1	175	2	low	-40~125	231	9.5	142	8	XSON8	SOT1116	NAND gates
74LVC2G38GS	Production	LVC	NAND gates	Dual 2-input NANDgate; open-drain	1.65 - 5.5	CMOS/LVTTL	32	2.1	175	2	low	-40~125	269	9.7	141	8	XSON8	SOT1203	NAND gates
74LVC2G38GT	Production	LVC	NAND gates	Dual 2-input NANDgate; open-drain	1.65 - 5.5	CMOS/LVTTL	32	2.1	175	2	low	-40~125	317	5.6	150	8	XSON8	SOT833-1	NAND gates
74LVC2G38GX	Production	LVC	NAND gate	Dual 2-input NANDgate; open-drain	1.65 - 5.5	CMOS/LVTTL	32	2.1	175	2	low	-40~125				8	X2SON8	SOT1233	NAND gates
74LVC2G86DC	Production	LVC	EXCLUSIVE-OR gates	Dual 2-inputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.3	150	2	low	-40~125	200	32.4	110	8	VSSOP8	SOT765-1	EXCLUSIVE-OR gates
74LVC2G86DP	Production	LVC	EXCLUSIVE-OR gates	Dual 2-inputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.3	150	2	low	-40~125	210	18.8	104	8	TSSOP8	SOT505-2	EXCLUSIVE-OR gates
74LVC2G86GN	Production	LVC	EXCLUSIVE-OR gates	Dual 2-inputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.3	150	2	low	-40~125	231	9.5	142	8	XSON8	SOT1116	EXCLUSIVE-OR gates
74LVC2G86GS	Production	LVC	EXCLUSIVE-OR gates	Dual 2-inputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.3	150	2	low	-40~125	269	9.7	141	8	XSON8	SOT1203	EXCLUSIVE-OR gates
74LVC2G86GT	Production	LVC	EXCLUSIVE-OR gates	Dual 2-inputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.3	150	2	low	-40~125	317	5.6	150	8	XSON8	SOT833-1	EXCLUSIVE-OR gates
74LVC2G86GX	Production	LVC	EXCLUSIVE-OR gates	Dual 2-inputEXCLUSIVE-OR gate	1.65 - 5.5	CMOS/LVTTL	± 32	2.3	150	2	low	-40~125				8	X2SON8	SOT1233	EXCLUSIVE-OR gates
74LVC00ABQ	Production	LVC	NAND gates	Quad 2-input NANDgate	1.2 - 3.6	CMOS/LVTTL	± 24	2.1	150	4	low	-40~125	109	23.4	77	14	DHVQFN14	SOT762-1	NAND gates
74LVC00AD	Production	LVC	NAND gates	Quad 2-input NANDgate	1.2 - 3.6	CMOS/LVTTL	± 24	2.1	150	4	low	-40~125	112	22.6	70	14	SO14	SOT108-1	NAND gates
74LVC00APW	Production	LVC	NAND gates	Quad 2-input NANDgate	1.2 - 3.6	CMOS/LVTTL	± 24	2.1	150	4	low	-40~125	144	8.7	70	14	TSSOP14	SOT402-1	NAND gates
74LVC02ABQ	Production	LVC	NOR gates	Quad 2-input NOR gate	1.2 - 3.6	TTL	± 24	2.1	150	4	low	-40~125	109	23.2	77	14	DHVQFN14	SOT762-1	NOR gates
74LVC02AD	Production	LVC	NOR gates	Quad 2-input NOR gate	1.2 - 3.6	TTL	± 24	2.1	150	4	low	-40~125	111	22.3	70	14	SO14	SOT108-1	NOR gates
74LVC02APW	Production	LVC	NOR gates	Quad 2-input NOR gate	1.2 - 3.6	TTL	± 24	2.1	150	4	low	-40~125	143	8.6	70	14	TSSOP14	SOT402-1	NOR gates
74LVC08ABQ	Production	LVC	AND gates	Quad 2-input AND gate	1.2 - 3.6	TTL	± 24	2.1	150	4	low	-40~125	109	23.4	77	14	DHVQFN14	SOT762-1	AND gates
74LVC08AD	Production	LVC	AND gates	Quad 2-input AND gate	1.2 - 3.6	TTL	± 24	2.1	150	4	low	-40~125	112	22.6	70	14	SO14	SOT108-1	AND gates
74LVC08APW	Production	LVC	AND gates	Quad 2-input AND gate	1.2 - 3.6	TTL	± 24	2.1	150	4	low	-40~125	144	8.4	70	14	TSSOP14	SOT402-1	AND gates
74LVC10ABQ	Production	LVC	NAND gates	Triple 3-input NANDgate	1.2 - 3.6	CMOS/LVTTL	± 24	3.9	150	3	low	-40~125	108	22.5	76	14	DHVQFN14	SOT762-1	NAND gates
74LVC10AD	Production	LVC	NAND gates	Triple 3-input NANDgate	1.2 - 3.6	CMOS/LVTTL	± 24	3.9	150	3	low	-40~125	110	21.6	69	14	SO14	SOT108-1	NAND gates
74LVC10APW	Production	LVC	NAND gates	Triple 3-input NANDgate	1.2 - 3.6	CMOS/LVTTL	± 24	3.9	150	3	low	-40~125	143	8.4	69	14	TSSOP14	SOT402-1	NAND gates
74LVC11BQ	Production	LVC	AND gates	Triple 3-input ANDgate	1.2 - 3.6	TTL	± 24	3.7	150	3	low	-40~125	108	22.5	76	14	DHVQFN14	SOT762-1	AND gates
74LVC11D	Production	LVC	AND gates	Triple 3-input ANDgate	1.2 - 3.6	TTL	± 24	3.7	150	3	low	-40~125	110	21.6	69	14	SO14	SOT108-1	AND gates
74LVC11PW	Production	LVC	AND gates	Triple 3-input ANDgate	1.2 - 3.6	TTL	± 24	3.7	150	3	low	-40~125	143	8.4	69	14	TSSOP14	SOT402-1	AND gates
74LVC30ABQ	Production	LVC	NAND gates	8-input NAND gate	1.65 - 5.5	CMOS/LVTTL	± 24	3.6	175	1	low	-40~125	110	23.7	78	14	DHVQFN14	SOT762-1	NAND gates
74LVC30AD	Production	LVC	NAND gates	8-input NAND gate	1.65 - 5.5	CMOS/LVTTL	± 24	3.6	175	1	low	-40~125	112	22.5	70	14	SO14	SOT108-1	NAND gates
74LVC30APW	Production	LVC	NAND gates	8-input NAND gate	1.65 - 5.5	CMOS/LVTTL	± 24	3.6	175	1	low	-40~125	144	8.8	71	14	TSSOP14	SOT402-1	NAND gates
74LVC32ABQ	Production	LVC	OR gates	Quad 2-input OR gate	1.2 - 3.6	CMOS/LVTTL	± 24	2.1	150	4	low	-40~125	109	23.2	77	14	DHVQFN14	SOT762-1	OR gates
74LVC32AD	Production	LVC	OR gates	Quad 2-input OR gate	1.2 - 3.6	CMOS/LVTTL	± 24	2.1	150	4	low	-40~125	112	22.4	70	14	SO14	SOT108-1	OR gates
74LVC32APW	Production	LVC	OR gates	Quad 2-input OR gate	1.2 - 3.6	CMOS/LVTTL	± 24	2.1	150	4	low	-40~125	112	22	70	14	TSSOP14	SOT402-1	OR gates
74LVC86ABQ	Production	LVC	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate	1.2 - 3.6	CMOS/LVTTL	± 24	3	150	4	low	-40~125	106	21.2	74	14	DHVQFN14	SOT762-1	EXCLUSIVE-OR gates
74LVC86AD	Production	LVC	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate	1.2 - 3.6	CMOS/LVTTL	± 24	3	150	4	low	-40~125	108	20.4	67	14	SO14	SOT108-1	EXCLUSIVE-OR gates
74LVC86APW	Production	LVC	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate	1.2 - 3.6	CMOS/LVTTL	± 24	3	150	4	low	-40~125	141	7.9	67	14	TSSOP14	SOT402-1	EXCLUSIVE-OR gates
74LVC132ABQ	Production	LVC	NAND gates	Quad 2-input NANDgate Schmitt-trigger	1.2 - 3.6	CMOS/LVTTL	± 24	3.4	175	4	low	-40~125	108	22.6	76	14	DHVQFN14	SOT762-1	Schmitt-triggers
74LVC132AD	Production	LVC	NAND gates	Quad 2-input NANDgate Schmitt-trigger	1.2 - 3.6	CMOS/LVTTL	± 24	3.4	175	4	low	-40~125	111	21.9	69	14	SO14	SOT108-1	Schmitt-triggers
74LVC132APW	Production	LVC	NAND gates	Quad 2-input NANDgate Schmitt-trigger	1.2 - 3.6	CMOS/LVTTL	± 24	3.4	175	4	low	-40~125	143	8.4	69	14	TSSOP14	SOT402-1	Schmitt-triggers
74LVT02D	Production	LVT	NOR gates	Quad 2-input NOR gate	2.7 - 3.6	TTL	-32 / +64	2.8	150	4	medium	-40~85	108	20.3	67	14	SO14	SOT108-1	NOR gates
74LVT02PW	Production	LVT	NOR gates	Quad 2-input NOR gate	2.7 - 3.6	TTL	-32 / +64	2.8	150	4	medium	-40~85	141	7.9	67	14	TSSOP14	SOT402-1	NOR gates
74LVT08D	Production	LVT	AND gates	Quad 2-input AND gate	2.7 - 3.6	TTL	-32/+64	3.4	150	4	medium	-40~85	109	20.9	68	14	SO14	SOT108-1	AND gates
74LVT08PW	Production	LVT	AND gates	Quad 2-input AND gate	2.7 - 3.6	TTL	-32/+64	3.4	150	4	medium	-40~85	142	8.1	68	14	TSSOP14	SOT402-1	AND gates
74VHC02BQ	Production	VHC(T)	NOR gates	Quad 2-input NOR gate	2.0 - 5.5	CMOS	± 8	2.9	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	NOR gates
74VHC02D	Production	VHC(T)	NOR gates	Quad 2-input NOR gate	2.0 - 5.5	CMOS	± 8	2.9	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	NOR gates
74VHC02PW	Production	VHC(T)	NOR gates	Quad 2-input NOR gate	2.0 - 5.5	CMOS	± 8	2.9	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	NOR gates
74VHCT02BQ	Production	VHC(T)	NOR gates	Quad 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.8	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	NOR gates
74VHCT02D	Production	VHC(T)	NOR gates	Quad 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.8	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	NOR gates
74VHCT02PW	Production	VHC(T)	NOR gates	Quad 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.8	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	NOR gates
74VHC08BQ	Production	VHC(T)	AND gates	Quad 2-input AND gate	2.0 - 5.5	CMOS	± 8	3.5	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	AND gates
74VHC08D	Production	VHC(T)	AND gates	Quad 2-input AND gate	2.0 - 5.5	CMOS	± 8	3.5	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	AND gates
74VHC08PW	Production	VHC(T)	AND gates	Quad 2-input AND gate	2.0 - 5.5	CMOS	± 8	3.5	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	AND gates
74VHCT08BQ	Production	VHC(T)	AND gates	Quad 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	5	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	AND gates
74VHCT08D	Production	VHC(T)	AND gates	Quad 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	5	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	AND gates
74VHCT08PW	Production	VHC(T)	AND gates	Quad 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	5	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	AND gates
74VHC32BQ	Production	VHC(T)	OR gates	Quad 2-input OR gate	2.0 - 5.5	CMOS	± 8	3.5	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	OR gates
74VHC32D	Production	VHC(T)	OR gates	Quad 2-input OR gate	2.0 - 5.5	CMOS	± 8	3.5	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	OR gates
74VHC32PW	Production	VHC(T)	OR gates	Quad 2-input OR gate	2.0 - 5.5	CMOS	± 8	3.5	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	OR gates
74VHCT32BQ	Production	VHC(T)	OR gates	Quad 2-input OR gate;TTL enabled	4.5 - 5.5	TTL	± 8	5	60	4	low	-40~125	103	18.4	71	14	DHVQFN14	SOT762-1	OR gates
74VHCT32D	Production	VHC(T)	OR gates	Quad 2-input OR gate;TTL enabled	4.5 - 5.5	TTL	± 8	5	60	4	low	-40~125	105	17.8	63	14	SO14	SOT108-1	OR gates
74VHCT32PW	Production	VHC(T)	OR gates	Quad 2-input OR gate;TTL enabled	4.5 - 5.5	TTL	± 8	5	60	4	low	-40~125	138	6.9	64	14	TSSOP14	SOT402-1	OR gates
HEF4001BT	Production	HEF4000B	NOR gates	Quad 2-input NOR gate	3.0 - 15	CMOS	± 2.4	20	10	4	medium	-40~85	107	19.5	65	14	SO14	SOT108-1	NOR gates
HEF4002BT	Production	HEF4000B	NOR gates	Dual 4-input NORgate	3.0 - 15	CMOS	± 2.4	20	10	4	medium	-40~85	89	7.5	47	14	SO14	SOT108-1	NOR gates
HEF4007UBT	Production	HEF4000B	Combination gates	Dual complementarypair and inverter	3.0 - 15	CMOS	± 3.4	15	10	2	medium	-40~85	94	10.7	52	14	SO14	SOT108-1	Combination
HEF4011BT	Production	HEF4000B	NAND gates	Quad 2-input NANDgate	3.0 - 15	CMOS	± 2.4	20	10	4	medium	-40~85	107	19.7	66	14	SO14	SOT108-1	NAND gates
HEF4030BT	Production	HEF4000B	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate	3.0 - 15	CMOS	± 2.4	30	10	4	medium	-40~85	88	6.7	45	14	SO14	SOT108-1	EXCLUSIVE-OR gates
HEF4070BT	Production	HEF4000B	EXCLUSIVE-OR gates	Quad 2-inputEXCLUSIVE-OR gate	3.0 - 15	CMOS	± 2.4	30	10	4	medium	-40~85	91	8.9	49	14	SO14	SOT108-1	EXCLUSIVE-OR gates
HEF4071BT	Production	HEF4000B	OR gates	Quad 2-input OR gate	3.0 - 15	CMOS	± 2.4	20	10	4	medium	-40~125	106	18.8	64	14	SO14	SOT108-1	OR gates
HEF4073BT	Production	HEF4000B	AND gates	Triple 3-input ANDgate	3.0 - 15	CMOS	± 2.4	20	10	3	medium	-40~85	93	10.5	51	14	SO14	SOT108-1	AND gates
HEF4077BT	Production	HEF4000B	EXCLUSIVE-NOR gates	Quad 2-inputEXCLUSIVE-NOR gate	3.0 - 15	CMOS	± 2.4	30	10	4	medium	-40~85	93	10	51	14	SO14	SOT108-1	EXCLUSIVE-NOR gates
HEF4081BT	Production	HEF4000B	AND gates	Quad 2-input AND gate	3.0 - 15	CMOS	± 2.4	20	10	4	medium	-40~85	102	16.3	60	14	SO14	SOT108-1	AND gates
HEF4082BT	Production	HEF4000B	AND gates	Dual 4-input AND gate	3.0 - 15	CMOS	± 2.4	25	10	2	medium	-40~85	92	9.8	50	14	SO14	SOT108-1	AND gates
HEF4093BT	Production	HEF4000B	NAND gates	Quad 2-input NANDgate Schmitt-trigger	3.0 - 15	CMOS	± 2.4	30	10	4	medium	-40~125	106	18.6	64	14	SO14	SOT108-1	Schmitt-triggers
XC7SET02GV	Production	XC7	NOR gate	Single 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.5	60	1	low	-40~125	254	53.9	157	5	TSOP5	SOT753	NOR gates
XC7SET02GW	Production	XC7	NOR gate	Single 2-input NORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.5	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	NOR gates
XC7SET08GV	Production	XC7	AND gate	Single 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.6	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	AND gates
XC7SET08GW	Production	XC7	AND gate	Single 2-input ANDgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.6	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	AND gates
XC7SET32GV	Production	XC7	OR gate	Single 2-input ORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.3	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	OR gates
XC7SET32GW	Production	XC7	OR gate	Single 2-input ORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.3	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	OR gates
XC7SET86GV	Production	XC7	EXCLUSIVE-OR gate	2-input EXCLUSIVE-ORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.5	60	1	low	-40~125	259	56.4	160	5	TSOP5	SOT753	EXCLUSIVE-OR gates
XC7SET86GW	Production	XC7	EXCLUSIVE-OR gate	2-input EXCLUSIVE-ORgate; TTL enabled	4.5 - 5.5	TTL	± 8	3.5	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	EXCLUSIVE-OR gates
XC7SH02GV	Production	XC7	NOR gate	Single 2-input NORgate	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	NOR gates
XC7SH02GW	Production	XC7	NOR gate	Single 2-input NORgate	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	NOR gates
XC7SH08GV	Production	XC7	AND gate	Single 2-input ANDgate	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	AND gates
XC7SH08GW	Production	XC7	AND gate	Single 2-input ANDgate	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	AND gates
XC7SH32GV	Production	XC7	OR gate	Single 2-input ORgate	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	OR gates
XC7SH32GW	Production	XC7	OR gate	Single 2-input ORgate	2.0 - 5.5	CMOS	± 8	3.2	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	OR gates
XC7SH86GV	Production	XC7	EXCLUSIVE-OR gate	2-input EXCLUSIVE-ORgate	2.0 - 5.5	CMOS	± 8	3.4	60	1	low	-40~125	272	64.5	170	5	TSOP5	SOT753	EXCLUSIVE-OR gates
XC7SH86GW	Production	XC7	EXCLUSIVE-OR gate	2-input EXCLUSIVE-ORgate	2.0 - 5.5	CMOS	± 8	3.4	60	1	low	-40~125	312	82.5	183	5	TSSOP5	SOT353-1	EXCLUSIVE-OR gates

微处理器

电源与外围

汽车电子

物联网（IoT）解决方案

汽车电子解决方案

Nexperia 逻辑门

关键应用
