i.MX 7系列提供了高度集成的应用程序处理器,代表了恩智浦在超低功耗处理领域的最新成就,适用于要求超长电池寿命的应用,旨在支持物联网中的安全和便携式应用程序。

i.MX 7ULP系列

i.MX 7ULP系列处理器面向新兴的便携式设备市场,基于Arm®Cortex®-A7内核和Arm® Cortex®-M4内核,以及3D和2D图形处理单元(GPU)。i.MX 7ULP系列提供32位LPDDR2/LPDDR3存储器接口和一些其它接口,用于连接外围设备,诸如WLAN、蓝牙®、GPS、显示器和摄像头传感器。

  • Single Arm® Cortex®-A7 core
  • Cortex®-M4 core
  • 256 KB L2 cache
  • Total of 512 KB of on-chip RAM
  • 16-/32-bit LPDDT2/3
  • Full security w/tamper resist
  • Separate system power domains with IPC

i.MX 7Solo系列

i.MX 7Solo系列处理器基于Arm® Cortex®-A7 和Arm Cortex®-M4内核,其中A7内核运行速度高达1 GHz。i.MX 7Solo系列支持多种存储器类型,包括16/32位DDR3L/LPDDR2/LPDDR3-1066、Quad SPI存储器、NAND、eMMC和NOR。通过AVB和USB支持包括千兆以太网在内的7种高速连接。提供并行和串行显示屏和摄像头接口。

  • Single Arm® Cortex®-A7 up to 800 MHz
  • Cortex®-M4 up to 200 MHz
  • 512 KB L2 cache
  • 16-/32-bit DDR3/DDR3L and LPDDR2/3 at 533 MHz
  • Single Gigabit Ethernet(AVB)
  • USB 2.0 OTG(w/PHY)
  • Full security w/tamper resist

i.MX 7Dual系列

i.MX 7Dual使用Arm®通用Cortex®-A7和Cortex®-M4内核可编程处理。异构不对称架构为客户提供了最大的灵活性,通过启用可以运行复杂功能的单芯片解决方案,操作系统并提供实时响应。处理器包含四个独立控制的资源域以实现最大的有效性和安全性。

  • Dual  Arm® Cortex®-A7 up to  1.2GHz
  • Cortex®-M4 up to 200 MHz
  • 512 KB L2 cache
  • 16-/32-bit DDR3/DDR3L and LPDDR2/3 at 533 MHz
  • Dual  Gigabit Ethernet(AVB)
  • Dual  USB 2.0 OTG(w/PHY)
  • Full security w/tamper resist
  • EPD controller
  • PCle (x1 lane)
选型表下载
Parts内核类型主频
[Max] (MHz)
内核数量
(SPEC)
协处理器类型协处理器主频
(MAX) (MHz)
L2 Cache
(Max)(KB)
SRAM (kB)支持的外部存储PCIe 2.0EthernetSPII2CUARTUSBCAN特定音频模块显示功能摄像头接口Package Type引脚间距 (mm)工作温度
(Min) (℃)
工作温度
(Max) (℃)
MCIMX7U3DVK07SCArm® Cortex®-A77201Arm® Cortex®-M4200256 LPDDR2DRAM, LPDDR3 DRAM, QSPI-048820SAIMIPI-DSI, VIU VFBGA3610.5095
MCIMX7U5DVK07SCArm® Cortex®-A77201Arm® Cortex®-M4200256 LPDDR2DRAM, LPDDR3 DRAM, QSPI-048820SAIMIPI-DSI, VIU VFBGA3610.5095
MCIMX7U5DVP07SCArm® Cortex®-A77201Arm® Cortex®-M4200256 LPDDR2DRAM, LPDDR3 DRAM, QSPI-048820SAIMIPI-DSI, VIU LFBGA3930.5095
MCIMX7S3DVK08SDArm® Cortex®-A78001Arm® Cortex®-M4200512256DDR3SDRAM, DDR3L SDRAM, ECC, LPDDR2 DRAM, LPDDR3 DRAM, NAND FLASH, NOR FLASH,QSPI-1 x 1 Gbps + IEEE 158844720SAIMIPI-CSI,MIPI-CSI-2, MIPI-DSI, PCP TFBGA4880.4095
MCIMX7S3EVK08SDArm® Cortex®-A78001Arm® Cortex®-M4200512256DDR3SDRAM, DDR3L SDRAM, ECC, LPDDR2 DRAM, LPDDR3 DRAM, NAND FLASH, NOR FLASH,QSPI-1 x 1 Gbps + IEEE 158844720SAIMIPI-CSI,MIPI-CSI-2, MIPI-DSI, PCP TFBGA4880.4-20105
MCIMX7S5EVK08SDArm® Cortex®-A78001Arm® Cortex®-M4200512256DDR3SDRAM, DDR3L SDRAM, ECC, LPDDR2 DRAM, LPDDR3 DRAM, NAND FLASH, NOR FLASH,QSPI-1 x 1 Gbps + IEEE 158844720SAIMIPI-CSI,MIPI-CSI-2, MIPI-DSI, PCP TFBGA4880.4-20105
MCIMX7S5EVM08SDArm® Cortex®-A78001Arm® Cortex®-M4200512256DDR3SDRAM, DDR3L SDRAM, ECC, LPDDR2 DRAM, LPDDR3 DRAM, NAND FLASH, NOR FLASH,QSPI-1 x 1 Gbps + IEEE 158844720SAIMIPI-CSI,MIPI-CSI-2, MIPI-DSI, PCP LFBGA5410.75-20105
MCIMX7D2DVK12SDArm® Cortex®-A712002Arm® Cortex®-M4F200512256DDR3L SDRAM, ECC, LPDDR2 DRAM, LPDDR3 DRAM, NAND FLASH, NOR FLASH, QSPI11 x 1 Gbps + IEEE 158844730SAIMIPI-DSI,parallel RGB LCD controller1 x MIPI-CSI-2,1 x parallel CSITFBGA4880.4085
MCIMX7D2DVM12SDArm® Cortex®-A712002Arm® Cortex®-M4F200512256DDR3L SDRAM, ECC, LPDDR2 DRAM, LPDDR3 DRAM, NAND FLASH, NOR FLASH, QSPI11 x 1 Gbps + IEEE 158844730SAIMIPI-DSI,parallel RGB LCD controller1 x MIPI-CSI-2,1 x parallel CSILFBGA5410.75085
MCIMX7D3DVK10SDArm® Cortex®-A710002Arm® Cortex®-M4F200512256DDR3L SDRAM, ECC, LPDDR2 DRAM, LPDDR3 DRAM, NAND FLASH, NOR FLASH, QSPI11 x 1 Gbps + IEEE 158844730SAIMIPI-DSI,parallel RGB LCD controller1 x MIPI-CSI-2,1 x parallel CSITFBGA4880.4095
MCIMX7D3EVK10SDArm® Cortex®-A710002Arm® Cortex®-M4F200512256DDR3L SDRAM, ECC, LPDDR2 DRAM, LPDDR3 DRAM, NAND FLASH, NOR FLASH, QSPI11 x 1 Gbps + IEEE 158844730SAIMIPI-DSI,parallel RGB LCD controller1 x MIPI-CSI-2,1 x parallel CSITFBGA4880.4-20105
MCIMX7D5EVK10SDArm® Cortex®-A710002Arm® Cortex®-M4F200512256DDR3SDRAM, DDR3L SDRAM, ECC, LPDDR2 DRAM, LPDDR3 DRAM, NAND FLASH, NOR FLASH,QSPI12 x 1 Gbps + IEEE 158844732SAIMIPI-DSI,parallel RGB LCD controller1 x MIPI-CSI-2,1 x parallel CSITFBGA4880.4-20105
MCIMX7D5EVM10SDArm® Cortex®-A710002Arm® Cortex®-M4F200512256DDR3L SDRAM, ECC, LPDDR2 DRAM, LPDDR3 DRAM, NAND FLASH, NOR FLASH, QSPI11 x 1 Gbps + IEEE 158844732SAIMIPI-DSI,parallel RGB LCD controller1 x MIPI-CSI-2,1 x parallel CSILFBGA5410.75-20105
MCIMX7D7DVK10SDArm® Cortex®-A710002Arm® Cortex®-M4F200512256DDR3L SDRAM, ECC, LPDDR2 DRAM, LPDDR3 DRAM, NAND FLASH, NOR FLASH, QSPI11 x 1 Gbps + IEEE 158844732SAIE-paperdisplay, MIPI-DSI, parallel RGB LCD controller1 x MIPI-CSI-2,1 x parallel CSITFBGA4880.4095
MCIMX7D7DVM10SDArm® Cortex®-A710002Arm® Cortex®-M4F200512256DDR3L SDRAM, ECC, LPDDR2 DRAM, LPDDR3 DRAM, NAND FLASH, NOR FLASH, QSPI11 x 1 Gbps + IEEE 158844732SAIE-paperdisplay, MIPI-DSI, parallel RGB LCD controller1 x MIPI-CSI-2,1 x parallel CSILFBGA5410.75095

开发板型号

  • MCIMX7ULP-EVK

支持芯片

  • i.MX 7ULP

资料下载

开发板型号

  • MCIMX7SABRE

支持芯片

  • i.MX7Solo
  • i.MX7Dual
